Sputter Resistant Speed Controller, Sputter Type Elbow
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Control Direction | Operating Pressure Range (MPa) | Nominal Diameter of Tube D | Nominal of Thread | Check valve specifications | |
|---|---|---|---|---|---|---|---|---|---|
15.81 € | 1 | 12 Days | Meter-Out | 0.05～0.5 | 4 | R1/8 | Spring-Return Specifications | ||
15.81 € | 1 | 12 Days | Meter-Out | 0.1～0.9 | 4 | R1/8 | Standard Specifications | ||
15.81 € | 1 | 12 Days | Meter-In | 0.05～0.5 | 4 | R1/8 | Spring-Return Specifications | ||
15.81 € | 1 | 12 Days | Meter-In | 0.1～0.9 | 4 | R1/8 | Standard Specifications | ||
11.94 € | 1 | 12 Days | Meter-Out | 0.05～0.5 | 4 | M5×0.8 | Spring-Return Specifications | ||
11.94 € | 1 | 12 Days | Meter-Out | 0.1～0.9 | 4 | M5×0.8 | Standard Specifications | ||
11.94 € | 1 | 12 Days | Meter-In | 0.1～0.9 | 4 | M5×0.8 | Standard Specifications | ||
17.01 € | 1 | 12 Days | Meter-Out | 0.05～0.5 | 6 | R1/8 | Spring-Return Specifications | ||
17.01 € | 1 | 12 Days | Meter-Out | 0.1～0.9 | 6 | R1/8 | Standard Specifications | ||
17.01 € | 1 | 12 Days | Meter-In | 0.05～0.5 | 6 | R1/8 | Spring-Return Specifications | ||
17.01 € | 1 | 12 Days | Meter-In | 0.1～0.9 | 6 | R1/8 | Standard Specifications | ||
18.43 € | 1 | 12 Days | Meter-Out | 0.05～0.5 | 6 | R1/4 | Spring-Return Specifications | ||
18.43 € | 1 | 12 Days | Meter-In | 0.05～0.5 | 6 | R1/4 | Spring-Return Specifications | ||
18.43 € | 1 | 12 Days | Meter-In | 0.1～0.9 | 6 | R1/4 | Standard Specifications | ||
23.64 € | 1 | 12 Days | Meter-In | 0.1～0.9 | 6 | R3/8 | Standard Specifications | ||
14.41 € | 1 | 12 Days | Meter-Out | 0.05～0.5 | 6 | M5×0.8 | Spring-Return Specifications | ||
14.41 € | 1 | 12 Days | Meter-Out | 0.1～0.9 | 6 | M5×0.8 | Standard Specifications | ||
14.41 € | 1 | 12 Days | Meter-In | 0.05～0.5 | 6 | M5×0.8 | Spring-Return Specifications | ||
14.41 € | 1 | 12 Days | Meter-In | 0.1～0.9 | 6 | M5×0.8 | Standard Specifications | ||
18.30 € | 1 | 12 Days | Meter-Out | 0.05～0.5 | 8 | R1/8 | Spring-Return Specifications | ||
18.30 € | 1 | 10 Days | Meter-Out | 0.1～0.9 | 8 | R1/8 | Standard Specifications | ||
18.30 € | 1 | 12 Days | Meter-In | 0.05～0.5 | 8 | R1/8 | Spring-Return Specifications | ||
18.30 € | 1 | 12 Days | Meter-In | 0.1～0.9 | 8 | R1/8 | Standard Specifications | ||
19.64 € | 1 | 12 Days | Meter-Out | 0.05～0.5 | 8 | R1/4 | Spring-Return Specifications | ||
19.65 € | 1 | 10 Days | Meter-Out | 0.1～0.9 | 8 | R1/4 | Standard Specifications | ||
19.64 € | 1 | 12 Days | Meter-In | 0.05～0.5 | 8 | R1/4 | Spring-Return Specifications | ||
19.64 € | 1 | 12 Days | Meter-In | 0.1～0.9 | 8 | R1/4 | Standard Specifications | ||
24.85 € | 1 | 12 Days | Meter-Out | 0.1～0.9 | 8 | R3/8 | Standard Specifications | ||
24.84 € | 1 | 12 Days | Meter-In | 0.1～0.9 | 8 | R3/8 | Standard Specifications | ||
27.02 € | 1 | 12 Days | Meter-Out | 0.1～0.9 | 8 | R1/2 | Standard Specifications | ||
27.02 € | 1 | 12 Days | Meter-In | 0.1～0.9 | 8 | R1/2 | Standard Specifications | ||
22.16 € | 1 | 12 Days | Meter-Out | 0.05～0.5 | 10 | R1/4 | Spring-Return Specifications | ||
22.16 € | 1 | 12 Days | Meter-Out | 0.1～0.9 | 10 | R1/4 | Standard Specifications | ||
22.16 € | 1 | 12 Days | Meter-In | 0.05～0.5 | 10 | R1/4 | Spring-Return Specifications | ||
22.16 € | 1 | 12 Days | Meter-In | 0.1～0.9 | 10 | R1/4 | Standard Specifications | ||
24.87 € | 1 | 12 Days | Meter-Out | 0.1～0.9 | 10 | R3/8 | Standard Specifications | ||
24.87 € | 1 | 12 Days | Meter-In | 0.1～0.9 | 10 | R3/8 | Standard Specifications | ||
28.26 € | 1 | 12 Days | Meter-Out | 0.1～0.9 | 10 | R1/2 | Standard Specifications | ||
28.26 € | 1 | 12 Days | Meter-In | 0.1～0.9 | 10 | R1/2 | Standard Specifications | ||
27.39 € | 1 | 12 Days | Meter-Out | 0.1～0.9 | 12 | R3/8 | Standard Specifications | ||
27.39 € | 1 | 12 Days | Meter-In | 0.1～0.9 | 12 | R3/8 | Standard Specifications | ||
28.96 € | 1 | 12 Days | Meter-Out | 0.1～0.9 | 12 | R1/2 | Standard Specifications | ||
28.96 € | 1 | 12 Days | Meter-In | 0.1～0.9 | 12 | R1/2 | Standard Specifications |
Loading...
Basic information
| Type | Speed Controller | Shape | Elbow | Joint Type | Screw, Tube Connection |
|---|---|---|---|---|---|
| Main Body Material | Brass | Usage Environment/Application | Sputtering Resistance | Thread Material | Brass |
| Knob Type | Standard | Lock Nut Type | Knurled | Operating Temperature Range(℃) | 0::60 |
| Adjusting Knob Cover | With Cover |
Configure
Basic Attributes
-
Control Direction
- Meter-In
- Meter-Out
-
Nominal Diameter of Tube D
-
Nominal of Thread
- R1/2
- R1/4
- R1/8
- R3/8
- M5×0.8
-
Check valve specifications
- Spring-Return Specifications
- Standard Specifications
-
Type
- JSC-V-0
-
Filter by CAD data type
- 3D
Filter by standard shipping days
-
- All
- 10 Days or Less
- 12 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
