Steel Plate Round Flange Shape
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| ASPF201 |
| ASPF202 |
| ASPF203 |
| ASPF204 |
| ASPF205 |
| ASPF206 |
| ASPF207 |
| ASPF208 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | Shaft Bore Dia. d (mm) | Basic Load Rating, Static Rating (N) | Basic Dynamic Load Rating Cr (N) | |
|---|---|---|---|---|---|---|---|---|
14.02 € | 1 | 8 Days | 10 | 12 | 4600 | 9600 | ||
14.02 € | 1 | 5 Days | 10 | 15 | 4600 | 9600 | ||
11.68 € 5.84 € | 1 |
Same day
Stock | 10 | 17 | 4600 | 9600 | ||
13.77 € 6.75 € | 1 |
Same day
Stock | - | 20 | 6650 | 12800 | ||
18.38 € | 1 | 5 Days | - | 25 | 7850 | 14000 | ||
24.99 € | 1 | 5 Days | - | 30 | 11300 | 19500 | ||
26.74 € | 1 | 8 Days | 10 | 35 | 15300 | 25700 | ||
32.56 € | 1 | Available | 8 Days | 10 | 40 | 17800 | 29100 |
Loading...
Basic information
| Unit, Type | Bearing unit | Bearing Unit, Type | Round flange shape | Unit Body Material | Steel Plate |
|---|---|---|---|---|---|
| Bearing Inner Dia. Shape | Cylindrical Bore Set Screw | Rolling Element Material | Steel | Surface Treatment | NA |
| Cover Type | NA | Seal | Standard Nitrile Rubber Seal | Lubrication method | Oil-Free Type |
| Temperature Properties | Standard | Set Screws | Set Screw with Ball |
Configure
Stock
-
- Show only stock items
Basic Attributes
-
Shaft Bore Dia. d(mm)
-
Basic Dynamic Load Rating Cr(N)
-
Type
- ASPF
-
Filter by CAD data type
- 2D
- 3D
Filter by standard shipping days
-
- All
- Same day
- 5 Days or Less
- 8 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
