Resin Screw (PPS / Washer)_SPS-W【1-20 Pieces Per Package】
- Promotional pricing ends 31/12/2024
- Volume Discount
· PPS has an excellent heat resistance, and can be used continuously at 200°C. Offers excellent chemical resistance. Excellent chemical-resistant, under 200°C PPS melting lipids or active solvents are not contained.
· Boasts high strength and rigidity, and also maintains its strength at high temperatures.
· Non-viscous and offers excellent abrasion resistance and electrical properties.
· Heat resistant temperature: 200°C (UL certified). UL standard 94 V-0 passed with superior flame retardancy.
· FPDsuitable for chemical resistant applications such as FPD manufacturing equipment, semiconductor manufacturing equipment, printed circuit board etching equipment, metal surface treatment facilities and chemical plants.
· Suitable for heat resistant applications such as hot water pumps and chemical pumps. Suitable for electrical and electronic fields such as transformers, and computer equipment.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| SPS-3-W |
| SPS-3-W-VA |
| SPS-4-W |
| SPS-4-W-VA |
| SPS-5-W |
| SPS-5-W-VA |
| SPS-6-W |
| SPS-6-W-VA |
| SPS-8-W |
| SPS-8-W-VA |
| SPS-10-W |
| SPS-10-W-VA |
| SPS-12-W |
| SPS-12-W-VA |
| Part Number |
Standard Unit Price
| Number of pc(s). included in pkg. | Minimum order quantity | Volume Discount | RoHS | I.D. d (mm) | Thickness t (mm) | Sales Unit | Color | |
|---|---|---|---|---|---|---|---|---|---|---|
10.68 € | 20 Pieces Per Package | 1 pack | 6 Days | - | 3.2 | 0.5 | Box/Package | IV (Ivory) | ||
2.79 € | 1 | Available | 8 Days | 10 | 3.2 | 0.5 | Low Quantity (can be purchased from one) | - | ||
11.70 € | 20 Pieces Per Package | 1 pack | 6 Days | - | 4.3 | 0.8 | Box/Package | IV (Ivory) | ||
2.89 € | 1 | Available | 8 Days | 10 | 4.3 | 0.8 | Low Quantity (can be purchased from one) | - | ||
13.77 € | 20 Pieces Per Package | 1 pack | 6 Days | - | 5.3 | 1 | Box/Package | IV (Ivory) | ||
2.96 € | 1 | Available | 8 Days | 10 | 5.3 | 1 | Low Quantity (can be purchased from one) | - | ||
7.58 € | 10 Pieces Per Package | 1 pack | 8 Days | - | 6.4 | 1.6 | Box/Package | IV (Ivory) | ||
2.96 € | 1 | Available | 8 Days | 10 | 6.4 | 1.6 | Low Quantity (can be purchased from one) | - | ||
19.64 € | 10 Pieces Per Package | 1 pack | 6 Days | - | 8.4 | 1.6 | Box/Package | IV (Ivory) | ||
3.65 € | 1 | Available | 8 Days | 10 | 8.4 | 1.6 | Low Quantity (can be purchased from one) | - | ||
8.69 € 6.08 € | 5 Pieces Per Package | 1 pack | Available |
Same day
Stock | - | 10.5 | 2 | Box/Package | IV (Ivory) | |
2.67 € | 1 | Available | 6 Days | - | 10.5 | 2 | Low Quantity (can be purchased from one) | - | ||
16.22 € | 5 Pieces Per Package | 1 pack | 8 Days | - | 13 | 2.5 | Box/Package | IV (Ivory) | ||
2.88 € 2.02 € | 1 | Available |
Same day
Stock | - | 13 | 2.5 | Low Quantity (can be purchased from one) | - |
Loading...
Basic information
| Type (Application) | Flat Washer | Type | Flat Washer | Material | Resin |
|---|---|---|---|---|---|
| Surface Treatment | NA | Material, Resin | PPS (Polyphenylene sulfide) | Surface Treatment (Details) | NA |
