IMAO CORPORATION

Hex Socket Balls Plunger (with Long Lock) (LBST-A, LBSTH-A)

Hex Socket Balls Plunger (with Long Lock) (LBST-A, LBSTH-A)

Part number:

Still undefined. 16 possible part numbers found.
Quantity:

Part number list

Number of items
  • 1
    • Part number
    LBST3A
    LBST4A
    LBST5A
    LBST6A
    LBST8A
    LBST10A
    LBST12A
    LBST16A
    LBSTH3A
    LBSTH4A
    LBSTH5A
    LBSTH6A
    LBSTH8A
    LBSTH10A
    LBSTH12A
    LBSTH16A

    Outer Diameter D (or Male Thread M)

    (mm)

    Stroke S

    (mm)

    Vertical Load (Range)

    (N)

    Minimum Load

    (N)

    Maximum Load Capacity

    (N)

    Length L

    (mm)

    Tip outer diameter d

    (φ)

    Thread Pitch

    (mm)

    Load Identification

    Mounting moment

    (N▪m)

    Remove moment

    (N▪m)

    		RoHS?Minimum order quantity
    3
    0.5
    0.01 to 50
    1.5
    3
    9
    1.5
    0.5
    For Light Loads (no line)
    0.1
    0.07
    10
    1 pieces
    4
    0.8
    0.01 to 50
    4
    10
    10
    2.5
    0.7
    For Light Loads (no line)
    0.18
    0.12
    10
    1 pieces
    5
    0.9
    0.01 to 50
    6
    11
    14
    3
    0.8
    For Light Loads (no line)
    0.12
    0.08
    10
    1 pieces
    6
    1
    0.01 to 50
    9
    13
    15
    3.5
    1
    For Light Loads (no line)
    0.44
    0.21
    10
    1 pieces
    8
    1.5
    0.01 to 50
    15
    30
    18
    5
    1.25
    For Light Loads (no line)
    1.1
    0.38
    10
    1 pieces
    10
    2
    0.01 to 50
    20
    35
    23
    6
    1.5
    For Light Loads (no line)
    1.3
    0.6
    10
    1 pieces
    12
    2.5
    0.01 to 50
    30
    55
    26
    8
    1.75
    For Light Loads (no line)
    2
    1.3
    10
    1 pieces
    16
    3.5
    50.01 to 100
    65
    125
    33
    10
    2
    For Light Loads (no line)
    3.9
    3
    10
    1 pieces
    3
    0.5
    0.01 to 50
    5
    7
    9
    1.5
    0.5
    For heavy loads (2 lines)
    0.1
    0.07
    10
    1 pieces
    4
    0.8
    0.01 to 50
    12
    22
    10
    2.5
    0.7
    For heavy loads (2 lines)
    0.18
    0.12
    10
    1 pieces
    5
    0.9
    0.01 to 50
    19
    30
    14
    3
    0.8
    For heavy loads (2 lines)
    0.12
    0.08
    10
    1 pieces
    6
    1
    0.01 to 50
    28
    40
    15
    3.5
    1
    For heavy loads (2 lines)
    0.44
    0.21
    10
    1 pieces
    8
    1.5
    0.01 to 50
    47
    73
    18
    5
    1.25
    For heavy loads (2 lines)
    1.1
    0.38
    10
    1 pieces
    10
    2
    50.01 to 100
    66
    100
    23
    6
    1.5
    For heavy loads (2 lines)
    1.3
    0.6
    10
    1 pieces
    12
    2.5
    50.01 to 100
    66
    120
    26
    8
    1.75
    For heavy loads (2 lines)
    2
    1.3
    10
    1 pieces
    16
    3.5
    50.01 to 100
    90
    180
    33
    10
    2
    For heavy loads (2 lines)
    3.9
    3
    10
    1 pieces
    Unit price (excluding VAT)(Unit price including VAT)
    Standard shipping days
    6.04 €
    ( 7.19 € )
    6 working days
    4.90 €
    ( 5.83 € )
    6 working days
    4.90 €
    ( 5.83 € )
    6 working days
    5.48 €
    ( 6.52 € )
    6 working days
    6.49 €
    ( 7.72 € )
    6 working days
    6.88 €
    ( 8.19 € )
    6 working days
    12.14 €
    ( 14.45 € )
    8 working days
    17.40 €
    ( 20.71 € )
    8 working days
    6.47 €
    ( 7.70 € )
    6 working days
    4.90 €
    ( 5.83 € )
    6 working days
    4.90 €
    ( 5.83 € )
    6 working days
    6.04 €
    ( 7.19 € )
    6 working days
    7.41 €
    ( 8.82 € )
    6 working days
    7.91 €
    ( 9.41 € )
    6 working days
    13.73 €
    ( 16.34 € )
    6 working days
    20.14 €
    ( 23.97 € )
    8 working days
  • 1

    • More Information

    Basic information

    Type with locking attachment. Can be attached using a hexagonal wrench. For each screw diameter two types of loads have been prepared.

    [Features]
    - A marking is attached to the rear surface of each product for product identification.
    - LBSUH: With 2 line loosening prevention function (long lock).
    - Strong against vibration, detachment moment is high, for reliable positioning.
    - The loosening prevention function will work for up to approximately 20 insertions and detachments.
