Groove Type Code Drawer Type Photo/ Micro-Sensor (DC Light) [EE-SX67-WR]
![Groove Type Code Drawer Type Photo/ Micro-Sensor (DC Light) [EE-SX67-WR]](http://uk.misumi-ec.com/linked/material/mech/OMR1/PHOTO/OMR1_221000419818.jpg?$product_main$)
50 to 100mA direct opening and closing, global standard groove type
[Features]
· Has wide variety of 8 shapes, power supply voltage is DC5 to 24V extensive.
· Code drawer type adopts robot code as standard.
[Features]
· Has wide variety of 8 shapes, power supply voltage is DC5 to 24V extensive.
· Code drawer type adopts robot code as standard.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| EE-SX671P-WR 1M |
| EE-SX674P-WR 1M |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Shape | Head maximum width (mm) | Head maximum, depth (mm) | |
|---|---|---|---|---|---|---|---|
46.63 € | 1 | 7 Days | L Type | 26.2 | 18.7 | ||
44.48 € | 1 | 6 Days | Solid Installation Type | 13.6 | 25.7 |
Loading...
Basic information
| Detection Distance(mm) | 5 | Head maximum height(mm) | 15.5 | Detection Method | Through Beam Type (Groove Type) |
|---|---|---|---|---|---|
| Luminescence Method | DC light (infrared light-emitting diode) | Operating Mode | With Dark ON/Light ON (switchable) | Output Format | PNP open collector output |
| Connection Method | Integrated Cable Type | Indicator Light Mode | Illuminated light (red) | Slit hole/width(mm) | - |
| Standard Detected Subject(mm) | 2 × 0.8mm or more of opaque body | Cord/cable specification | Robot cord φ2.8 mm, 4-core | Cord/cable length(mm) | 1000 |
| Groove depth(mm) | - | Protective Structure | IP50 | Mounting format | - |
| Between amplifiers(mm) | - | Applicable Pipe(φ) | - | Details Type | - |
Configure
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
