Deep groove ball bearings / single row / stainless / TOK BEARING

Part number:

Still undefined. 7 possible part numbers found.

Part number list

Number of items

Part number

Shield material and shape

I.D. D

(φ)

Outer Diameter D

(φ)

Width W

(mm)

Retainer Type

Mounting Type

Thread Part (Seating Height)

(mm)

Thread Length L (Referring to each type of the drawings)

(mm)

RoHS?

Minimum order quantity

Open Type	8	16	4	Pressed	Inner Wheel Hole(Standard Type)	-	-	10	1 pieces
Open Type	9	26	8	Pressed	Inner Wheel Hole(Standard Type)	-	-	10	1 pieces
Open Type	12	28	8	Pressed	Inner Wheel Hole(Standard Type)	-	-	10	1 pieces
Open Type	15	28	7	Pressed	Inner Wheel Hole(Standard Type)	-	-	10	1 pieces
Double Shielded	-	22	7	N/A	Screw Shaft	2.0	8.0	10	1 pieces
Open Type	-	30	7	N/A	Screw Shaft	0.5	8.0	10	1 pieces
Double Shielded	-	30	7	N/A	Screw Shaft	6.0	12.0	10	1 pieces

Unit price (excluding VAT)(Unit price including VAT)	Standard shipping days

45.35 € ( 53.97 € )	5 working days
45.19 €22.60 € ( 26.89 € )	Stock item - 1 working dayAvailable for same-day shipping
45.50 € ( 54.15 € )	5 working days
45.46 € ( 54.10 € )	5 working days
9.27 € ( 11.03 € )	5 working days
14.83 € ( 17.65 € )	5 working days
14.88 € ( 17.71 € )	5 working days

A bearing in which stainless steel is used for the outer race, inner race and ball.
