Suspension Cup SUSP Type Socket

Suspension Cup SUSP Type Socket
Stainless steel (SUS316) coupler that has undergone oil-free processing; uses sealing material that supports various types of chemical solutions in the semiconductor and physical/chemical industries.

[Features]
· SUSP type couplings have stainless steel SUS316 valve mechanisms provided in socket and plug parts and sealing materials compatible with various reagents for the semiconductor, biotechnology, and physics and chemical industries are used.
· High quality fitting that is corrosion resistant and inhibits chemical changes in organic solvents to a minimum.
· Both the main body and parts can be treated with electrolytic polishing, passivating, etc.

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Part Number
SUS-150-NBR
SUS-250-NBR
SUS-350-NBR
SUS-450-NBR
SUS-450-VT-20
SUS-650-NBR
SUS-650-VT-20
SUS-800-NBR
Part Number
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?
RoHSSealing Material Operating Temperature Range
(℃)
Operating Pressure Range
(MPa)
Type of Connection Thread T Minimum Sectional Area
(mm2)

57.78 €

1 9 Days 10[NBR] Nitrile Rubber-20~800~7.4Rc1/810

58.19 €

1 9 Days 10[NBR] Nitrile Rubber-20~800~7.4Rc1/418

73.44 €

1 9 Days 10[NBR] Nitrile Rubber-20~800~7.4Rc3/845

110.37 €

1 9 Days 10[NBR] Nitrile Rubber-20~800~4.4Rc1/290

122.42 €

1 5 Days 10[Fluororubber] Fluorine Rubber-15~1800~4.4Rc1/290

139.25 €

1 9 Days 10[NBR] Nitrile Rubber-20~800~4.4Rc3/4175

154.21 €

1 5 Days 10[Fluororubber] Fluorine Rubber-15~1800~4.4Rc3/4175

230.51 €

1 9 Days 10[NBR] Nitrile Rubber-20~800~4.4Rc1285

Loading...

  1. 1

Basic information

Type Standard Types of connection parts Female Threaded Plug (Male) / Socket (Female) Socket (female)
Main Body Material Stainless Steel (EN 1.4401 Equiv.) Applicable Fluids Water / Air / Chemical Structure of Valve Double passages opening closing type
Operating Environment/Applications Standard / Industrial Machinery / Semiconductor Manufacturing Equipment / Physics and chemistry equipments
