Vertical Pipe Fittings, TNF Standing Band (Electrogalvanized / Stainless Steel)
- Volume Discount
•Hinged standing band for cast iron drain pipe.<
· Zinc Plating Finish.
· Made of SUS304
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| A14207-0019 |
| A14207-0023 |
| A14207-0038 |
| A14207-0042 |
| A14207-0057 |
| A14207-0061 |
| A14207-0076 |
| A14207-0095 |
| A14207-0108 |
| A16001-0013 |
| A16001-0028 |
| A16001-0032 |
| A16001-0047 |
| A16001-0051 |
| A16001-0066 |
| A16001-0085 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Main fit tube(or application tube)outside diameter (mm) | Material | Surface Treatment | Size | Compatible Pipe Outer Diameter (mm) | |
|---|---|---|---|---|---|---|---|---|---|
3.11 € | 1 | Available |
Same day
Stock | 60～Less than 70 | [Steel] Steel | [Zinc Plating] Electrogalvanizing | 40 | 60~61 | |
2.15 € | 1 |
Same day
Stock | 70～Less than 80 | [Steel] Steel | [Zinc Plating] Electrogalvanizing | 50 | 73 | ||
2.31 € | 1 |
Same day
Stock | 80～Less than 90 | [Steel] Steel | [Zinc Plating] Electrogalvanizing | 65 | 89 | ||
4.40 € | 1 | 10 Days | 100～Less than 200 | [Steel] Steel | [Zinc Plating] Electrogalvanizing | 75 | 102 | ||
2.85 € | 1 | Available |
Same day
Stock | 100～Less than 200 | [Steel] Steel | [Zinc Plating] Electrogalvanizing | 100 | 128~129 | |
6.31 € | 1 |
Same day
Stock | 100～Less than 200 | [Steel] Steel | [Zinc Plating] Electrogalvanizing | 125 | 155~156 | ||
7.17 € | 1 |
Same day
Stock | 100～Less than 200 | [Steel] Steel | [Zinc Plating] Electrogalvanizing | 150 | 183 | ||
2.18 € | 1 | Available |
Same day
Stock | 40～Less than 50 | [Steel] Steel | [Zinc Plating] Electrogalvanizing | 25 | 45 | |
2.91 € | 1 | Available |
Same day
Stock | 50～Less than 60 | [Steel] Steel | [Zinc Plating] Electrogalvanizing | 30 | 51 | |
15.65 € | 1 | 9 Days | 60～Less than 70 | [Stainless Steel] Stainless Steel (EN 1.4301 Equiv.) | NA | 40 | 60~61 | ||
17.72 € | 1 | 13 Days | 70～Less than 80 | [Stainless Steel] Stainless Steel (EN 1.4301 Equiv.) | NA | 50 | 73 | ||
19.41 € | 1 | 13 Days | 80～Less than 90 | [Stainless Steel] Stainless Steel (EN 1.4301 Equiv.) | NA | 65 | 89 | ||
20.39 € | 1 | 13 Days | 100～Less than 200 | [Stainless Steel] Stainless Steel (EN 1.4301 Equiv.) | NA | 75 | 102 | ||
22.08 € | 1 | 13 Days | 100～Less than 200 | [Stainless Steel] Stainless Steel (EN 1.4301 Equiv.) | NA | 100 | 128~129 | ||
42.48 € | 1 | 9 Days | 100～Less than 200 | [Stainless Steel] Stainless Steel (EN 1.4301 Equiv.) | NA | 125 | 155~156 | ||
50.83 € | 1 | 9 Days | 100～Less than 200 | [Stainless Steel] Stainless Steel (EN 1.4301 Equiv.) | NA | 150 | 183 |
Loading...
Basic information
| Type | Vertical band | Compatible Pipe Type | FDP | Number Contained In A Packet(piece) | 1 |
|---|
Configure
Stock
-
- Show only stock items
Basic Attributes
-
Main fit tube(or application tube)outside diameter(mm)
-
Material
- Steel
- Stainless Steel
- Steel
-
Surface Treatment
- NA
- Zinc Plating
-
Size
- 25
- 30
- 40
- 50
- 65
- 75
- 100
- 125
- 150
-
Compatible Pipe Outer Diameter(mm)
- 45
- 51
- 60~61
- 73
- 89
- 102
- 128~129
- 155~156
- 183
-
Type
- A14207
- A16001
Filter by standard shipping days
-
- All
- Same day
- 9 Days or Less
- 10 Days or Less
- 13 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
