Ultra Compact Basic Switch D2S
- Volume Discount
[Features]
· Ultra compact series with excellent flux resistance.
· Integral molded terminal structure with no creeping up of flux.
· Accuracy of operation position is ±0.25 mm and easy to decide multilateral, peripheral design and position.
· Pin push button type easy to operate even in horizontal operation.
· Ultra compact series with excellent flux resistance.
· Integral molded terminal structure with no creeping up of flux.
· Accuracy of operation position is ±0.25 mm and easy to decide multilateral, peripheral design and position.
· Pin push button type easy to operate even in horizontal operation.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
D2S-5
Basic information
| Detector Shape | Plunger Type | AC rated operating voltage(V) | 250 | Kings of Plunger Type | Top Plunger |
|---|---|---|---|---|---|
| Operating Temperature Range(°C) | -25::85 | Acquisition of Standard Approval | UL / CSA | Protective Structure | IEC IP40 |
| Main Body Material | Thermoplastic | Required force to push side, O.F.(N) | ~2 | Movement up to switching, P.T.(mm) | 0.7 |
| Contact type | Single Pole Double Throw | Types of contact point | Rivet | Contact Material | Silver alloy |
| Mechanical Life(x10K times) | 3000 | Operation Frequency of Machine(times/min. or Less) | 400 | Rated Current(A) | 5 |
| Main Body External Shape Width W(mm) | 6.4 | Main Body External Shape Height H(mm) | 9.7 | Main Body External Shape Length L(mm) | 19.8 |
| Current type | AC | Actuator type | Pin push button type | Terminal Specification | Solder Terminal |
| Required force for push side, O.F. (detailed numerical values)(N) | 1.47 |
This page is Ultra Compact Basic Switch D2S, part number D2S-5.
You can find the detail information about specifications and dimensions on part number D2S-5.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
