Eight Lock Series Sleeve for Replacement
- Volume Discount
Eight lock dedicated sleeve for replacement.
[Features]
· Band position, torque control, and tightening such as that for Takenoko + band tightening is not required.
· Product allows uniform assembly by everybody at the work site.
· The inner surface of the main body is flat and rubber packing is not used, allowing the use of SUS304 for the liquid contact area and resistant fluids for the brass.
· No need to worry about effluent from the packing.
· A Hakko proprietary laminated hose can be used for a wide range of applications
[Features]
· Band position, torque control, and tightening such as that for Takenoko + band tightening is not required.
· Product allows uniform assembly by everybody at the work site.
· The inner surface of the main body is flat and rubber packing is not used, allowing the use of SUS304 for the liquid contact area and resistant fluids for the brass.
· No need to worry about effluent from the packing.
· A Hakko proprietary laminated hose can be used for a wide range of applications
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| E-EL-12-SL |
| E-EL-15-SL |
| E-EL-19-SL |
| E-EL-25-SL |
| E-EL-32-SL |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Applicable (suitable) hose size internal diameter x outer diameter (mm) | |
|---|---|---|---|---|---|
5.01 € | 1 | Available | 6 Days | 12×18 | |
5.65 € | 1 | 10 Days | 15×22 | ||
6.30 € | 1 | 10 Days | 19×26 | ||
6.91 € | 1 | 10 Days | 25×33 | ||
7.56 € | 1 | 10 Days | 32×41 |
Loading...
Basic information
| Type | Sleeve for Replacement | Main Body Material | POM |
|---|
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
