6S Series EN 1.4301 Equiv. Stainless Steel Bearing

Catalog

Part number:

Still undefined. 77 possible part numbers found.

Part number list
More Information
Catalog

Part number list

Number of items

Part number

Shield material and shape

I.D. D

(φ)

Outer Diameter D

(φ)

Width

(mm)

Basic Dynamic Load Rating Cr

(N)

Basic Static Load Rating Cor

(N)

Shield Shape

Shield Material

Sealing Material

RoHS?

Minimum order quantity

Double Shielded	10	26	8	92	59	Double Shielded	Stainless Steel (EN 1.4301 Equiv.)	-	10	1 pieces
Open Type	12	28	8	102	72	Open	-	-	10	1 pieces
Open Type	15	32	9	112	85	Open	-	-	10	1 pieces
Rubber Sealed	15	32	9	112	85	Double Sealed	-	Nitrile Rubber	10	1 pieces
Double Shielded	15	32	9	112	85	Double Shielded	Stainless Steel (EN 1.4301 Equiv.)	-	10	1 pieces
Open Type	17	35	10	120	98	Open	-	-	10	1 pieces
Rubber Sealed	17	35	10	120	98	Double Sealed	-	Nitrile Rubber	10	1 pieces
Double Shielded	17	35	10	120	98	Double Shielded	Stainless Steel (EN 1.4301 Equiv.)	-	10	1 pieces
Open Type	20	42	12	188	152	Open	-	-	10	1 pieces
Rubber Sealed	20	42	12	188	152	Double Sealed	-	Nitrile Rubber	10	1 pieces
Double Shielded	20	42	12	188	152	Double Shielded	Stainless Steel (EN 1.4301 Equiv.)	-	10	1 pieces
Open Type	25	47	12	201	176	Open	-	-	10	1 pieces
Double Shielded	25	47	12	201	176	Double Shielded	Stainless Steel (EN 1.4301 Equiv.)	-	10	1 pieces
Open Type	30	55	13	265	248	Open	-	-	10	1 pieces
Rubber Sealed	30	55	13	265	248	Double Sealed	-	Nitrile Rubber	10	1 pieces
Double Shielded	30	55	13	265	248	Double Shielded	Stainless Steel (EN 1.4301 Equiv.)	-	10	1 pieces
Open Type	35	62	14	320	310	Open	-	-	10	1 pieces
Rubber Sealed	35	62	14	320	310	Double Sealed	-	Nitrile Rubber	10	1 pieces
Double Shielded	35	62	14	320	310	Double Shielded	Stainless Steel (EN 1.4301 Equiv.)	-	10	1 pieces
Open Type	40	68	15	335	350	Open	-	-	10	1 pieces
Rubber Sealed	40	68	15	335	350	Double Sealed	-	Nitrile Rubber	10	1 pieces
Double Shielded	40	68	15	335	350	Double Shielded	Stainless Steel (EN 1.4301 Equiv.)	-	10	1 pieces
Open Type	8	22	7	66	41	Open	-	-	10	1 pieces
Double Shielded	8	22	7	66	41	Double Shielded	Stainless Steel (EN 1.4301 Equiv.)	-	10	1 pieces
Open Type	10	30	9	102	72	Open	-	-	10	1 pieces
Rubber Sealed	10	30	9	102	72	Double Sealed	-	Nitrile Rubber	10	1 pieces
Double Shielded	10	30	9	102	72	Double Shielded	Stainless Steel (EN 1.4301 Equiv.)	-	10	1 pieces
Open Type	12	32	10	136	91	Open	-	-	10	1 pieces
Rubber Sealed	12	32	10	136	91	Double Sealed	-	Nitrile Rubber	10	1 pieces
Double Shielded	12	32	10	136	91	Double Shielded	Stainless Steel (EN 1.4301 Equiv.)	-	10	1 pieces
Open Type	15	35	11	153	112	Open	-	-	10	1 pieces
Rubber Sealed	15	35	11	153	112	Double Sealed	-	Nitrile Rubber	10	1 pieces
Double Shielded	15	35	11	153	112	Double Shielded	Stainless Steel (EN 1.4301 Equiv.)	-	10	1 pieces
Rubber Sealed	17	40	12	191	144	Double Sealed	-	Nitrile Rubber	10	1 pieces
Double Shielded	17	40	12	191	144	Double Shielded	Stainless Steel (EN 1.4301 Equiv.)	-	10	1 pieces
Open Type	20	47	14	257	200	Open	-	-	10	1 pieces
Rubber Sealed	20	47	14	257	200	Double Sealed	-	Nitrile Rubber	10	1 pieces
Open Type	25	52	15	280	236	Open	-	-	10	1 pieces
Rubber Sealed	25	52	15	280	236	Double Sealed	-	Nitrile Rubber	10	1 pieces
Double Shielded	25	52	15	280	236	Double Shielded	Stainless Steel (EN 1.4301 Equiv.)	-	10	1 pieces
Open Type	30	62	16	390	340	Open	-	-	10	1 pieces
Rubber Sealed	30	62	16	390	340	Double Sealed	-	Nitrile Rubber	10	1 pieces
Double Shielded	30	62	16	390	340	Double Shielded	Stainless Steel (EN 1.4301 Equiv.)	-	10	1 pieces
Open Type	35	72	17	515	465	Open	-	-	10	1 pieces
Rubber Sealed	35	72	17	515	465	Double Sealed	-	Nitrile Rubber	10	1 pieces
Double Shielded	35	72	17	515	465	Double Shielded	Stainless Steel (EN 1.4301 Equiv.)	-	10	1 pieces
Open Type	40	80	18	580	540	Open	-	-	10	1 pieces
Rubber Sealed	40	80	18	580	540	Double Sealed	-	Nitrile Rubber	10	1 pieces
Double Shielded	40	80	18	580	540	Double Shielded	Stainless Steel (EN 1.4301 Equiv.)	-	10	1 pieces
Open Type	6	19	6	52	32	Open	-	-	10	1 pieces
Double Shielded	6	19	6	52	32	Double Shielded	Stainless Steel (EN 1.4301 Equiv.)	-	10	1 pieces
Open Type	8	24	8	67	42	Open	-	-	10	1 pieces
Rubber Sealed	8	24	8	67	42	Double Sealed	-	Nitrile Rubber	10	1 pieces
Double Shielded	8	24	8	67	42	Double Shielded	Stainless Steel (EN 1.4301 Equiv.)	-	10	1 pieces
Rubber Sealed	10	19	5	42	30	Double Sealed	-	Nitrile Rubber	10	1 pieces
Double Shielded	10	19	5	42	30	Double Shielded	Stainless Steel (EN 1.4301 Equiv.)	-	10	1 pieces
Open Type	10	22	6	54	38	Open	-	-	10	1 pieces
Rubber Sealed	10	22	6	54	38	Double Sealed	-	Nitrile Rubber	10	1 pieces
Double Shielded	10	22	6	54	38	Double Shielded	Stainless Steel (EN 1.4301 Equiv.)	-	10	1 pieces
Open Type	12	24	6	58	44	Open	-	-	10	1 pieces

Unit price (excluding VAT)(Unit price including VAT)	Standard shipping days

36.97 € ( 43.99 € )	6 working days
30.24 € ( 35.99 € )	6 working days
36.07 € ( 42.92 € )	6 working days
42.08 € ( 50.08 € )	6 working days
41.57 € ( 49.47 € )	13 working days
39.03 € ( 46.45 € )	14 working days
45.49 € ( 54.13 € )	14 working days
44.96 € ( 53.50 € )	11 working days
43.65 € ( 51.94 € )	6 working days
50.76 € ( 60.40 € )	14 working days
50.17 € ( 59.70 € )	6 working days
44.76 € ( 53.26 € )	6 working days
56.52 € ( 67.26 € )	6 working days
76.88 € ( 91.49 € )	14 working days
88.16 € ( 104.91 € )	14 working days
88.16 € ( 104.91 € )	6 working days
116.76 € ( 138.94 € )	14 working days
92.93 € ( 110.59 € )	14 working days
92.93 € ( 110.59 € )	14 working days
102.69 € ( 122.20 € )	14 working days
113.49 € ( 135.05 € )	14 working days
113.49 € ( 135.05 € )	14 working days
32.15 € ( 38.26 € )	6 working days
39.34 € ( 46.81 € )	6 working days
32.62 € ( 38.82 € )	6 working days
39.03 € ( 46.45 € )	14 working days
38.58 € ( 45.91 € )	11 working days
37.13 € ( 44.18 € )	6 working days
43.39 € ( 51.63 € )	14 working days
42.92 € ( 51.07 € )	6 working days
38.55 € ( 45.87 € )	6 working days
48.30 € ( 57.48 € )	14 working days
47.77 € ( 56.85 € )	13 working days
52.24 € ( 62.17 € )	14 working days
51.65 € ( 61.46 € )	13 working days
51.10 € ( 60.81 € )	6 working days
64.88 € ( 77.21 € )	14 working days
68.78 € ( 81.85 € )	14 working days
80.03 € ( 95.24 € )	14 working days
80.03 € ( 95.24 € )	14 working days
100.19 € ( 119.23 € )	14 working days
113.83 € ( 135.46 € )	14 working days
113.83 € ( 135.46 € )	14 working days
109.74 € ( 130.59 € )	14 working days
122.50 € ( 145.78 € )	14 working days
122.50 € ( 145.78 € )	14 working days
176.40 € ( 209.92 € )	14 working days
191.44 € ( 227.81 € )	14 working days
191.44 € ( 227.81 € )	14 working days
32.15 € ( 38.26 € )	6 working days
39.34 € ( 46.81 € )	6 working days
32.62 € ( 38.82 € )	14 working days
39.03 € ( 46.45 € )	13 working days
33.35 € ( 39.69 € )	6 working days
42.08 € ( 50.08 € )	14 working days
42.08 € ( 50.08 € )	14 working days
37.86 € ( 45.05 € )	14 working days
43.42 € ( 51.67 € )	14 working days
43.42 € ( 51.67 € )	14 working days
40.46 € ( 48.15 € )	14 working days

Basic information

Basic information

Stainless steel bearings made from SUS304 are widely used as corrosion- and heat-resistant steel and also as nonmagnetic steel. Most suitable in corrosive environments where it is difficult to use conventional SUS440C stainless steel bearings.

[Features]
· Because the bearing uses SUS304 stainless steel, which is widely used as corrosion- and heat-resistant steel and also as nonmagnetic steel, it has superior corrosion resistance to the general bearing steel, SUJ2, and SUS440C stainless steel bearings.
· SUS304 stainless steel is used for the inner and outer rings, balls, cage, and shield.
· Nitrile rubber is used for the seal as standard, but fluorine rubber seals and other seals are also available upon request.
· A silicon nitride ceramic ball can also be accommodated.
· Heat resistant grease is used for the SMI sealed SUS304 stainless steel bearings.
· Depending on the demand or application, heat- and chemical-resistant fluorine grease, grease for food equipment, and other special greases are also available
