Castors Unit with Adjuster SCY (Blickle)

Castors Unit with Adjuster SCY (Blickle)
  • Promotional pricing ends 30/11/2024
  • Volume Discount

SISIKU ADDKREIS

SISIKU ADDKREIS

Please refer to P80 to 91 for detailed material on "Compatible wheels." Furthermore, viewing of the "Gatefold version" of this catalog is recommended.

[Features]
· An integrated type in which movement is performed with the caster, fixing is done with the adjuster, and the bolt is used for adjustment.
· A design with excellent functionality and durability.
· An all-stainless steel construction version can also be made available (SCY-500 only)

Data sheet

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.


Data to be displayed
30
45
60
  1. 1
Part Number
SCY-250-YN
SCY-350-MC
SCY-350-YN
Part Number
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?
Mounting Height H
(mm) 		Load Range
(daN) 		Allowable Load
(daN) 		Wheel Material Wheel Characteristics Mounting Hole Pitch Length
(mm) 		Mounting Hole Pitch Width
(mm) 		Mounting SeatLength
(mm) 		Mounting Seat Width
(mm) 		Wheel Diameter
(mm) 		Rim Width
(mm) 		Load Category Detailed Wheel Specifications Wheel color Eccentricity
(mm)

92.65 €

1 9 Days 88220.01~320.00245[Nylon] Nylon 6Abrasion Resistance / Gasoline Resistance (Light Oil included) / Oil Resistance60(45)60(45)1351355032.5-(Core: None)Black18

105.49 €

73.84 €

1 Available Same day

Stock

96320.01~485.00343[Nylon] Monomer Casting NylonAbrasion Resistance / Gasoline Resistance (Light Oil included) / Oil Resistance / Chemical Resistance65(60)65(60)1551556536Heavy LoadOil ResistanceBlue22

108.74 €

1 9 Days 96320.01~485.00343[Nylon] Nylon 6Abrasion Resistance / Gasoline Resistance (Light Oil included) / Oil Resistance65(60)65(60)1551556536-(Core: None)Black22

Loading...

  1. 1

Basic information

Caster Type Plate Type Universal / With Adjuster Stopper NA Fitting Material Steel
Mounting Hole Type Round Hole Application OA equipment, information and communication equipment / Factory facilities Metal Fitting Color (Finish) Trivalent Chromate
Specifications The wheels on earth Floor Protection No Floor Protection Bearing Radial ball bearings
