Polyvinyl Chloride (PVC) / Hex Bolt
- Volume Discount
[Mounting hole dimensions] Hex Socket
[Basic shape] Standard (Round)
[Materials] Resin
[Surface treatment](Details) none
[Thread ridge type] Metric coarse
[Additional shapes] Standard
[Sales unit] Minimum Quantity (Available for Purchase from 1 pc)
[Application] Standard, Resin
[Materials] PVC
[Nominal Thread (M)] 3 4 5 6 8
[Length L or l (mm)] 8 10 12 15 20 25 30 35 40
[Pitch (mm)] 0.5 0.7 0.8 1 1.25 B 2.5 3 4 5 6 D 5.5 7 8.5 10 13 H 3 4 5 6 8
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | Nominal of Thread (M) | Length L or l (mm) | Pitch (mm) | B | D | H | |
|---|---|---|---|---|---|---|---|---|---|---|---|
0.99 € | 1 | Available |
Same day
Stock | 10 | 3 | 8 | 0.5 | 2.5 | 5.5 | 3 | |
1.74 € | 1 | Available |
Same day
Stock | 10 | 3 | 10 | 0.5 | 2.5 | 5.5 | 3 | |
1.01 € | 1 | Available |
Same day
Stock | 10 | 3 | 12 | 0.5 | 2.5 | 5.5 | 3 | |
1.12 € | 1 | Available |
Same day
Stock | 10 | 3 | 15 | 0.5 | 2.5 | 5.5 | 3 | |
1.15 € | 1 | Available |
Same day
Stock | 10 | 3 | 20 | 0.5 | 2.5 | 5.5 | 3 | |
1.15 € | 1 | Available |
Same day
Stock | 10 | 3 | 25 | 0.5 | 2.5 | 5.5 | 3 | |
1.03 € | 1 | Available |
Same day
Stock | 10 | 4 | 10 | 0.7 | 3 | 7 | 4 | |
1.05 € | 1 | Available |
Same day
Stock | 10 | 4 | 12 | 0.7 | 3 | 7 | 4 | |
1.19 € | 1 | Available |
Same day
Stock | 10 | 4 | 25 | 0.7 | 3 | 7 | 4 | |
1.08 € | 1 | Available |
Same day
Stock | 10 | 5 | 10 | 0.8 | 4 | 8.5 | 5 | |
1.18 € | 1 | Available |
Same day
Stock | 10 | 5 | 15 | 0.8 | 4 | 8.5 | 5 | |
1.34 € | 1 | Available |
Same day
Stock | 10 | 5 | 25 | 0.8 | 4 | 8.5 | 5 | |
1.48 € | 1 | Available |
Same day
Stock | 10 | 5 | 30 | 0.8 | 4 | 8.5 | 5 | |
0.96 € | 1 | 5 Days | 10 | 6 | 10 | 1 | 5 | 10 | 6 | ||
1.38 € | 1 | Available |
Same day
Stock | 10 | 6 | 15 | 1 | 5 | 10 | 6 | |
1.46 € | 1 | Available |
Same day
Stock | 10 | 6 | 25 | 1 | 5 | 10 | 6 | |
1.52 € | 1 | Available |
Same day
Stock | 10 | 6 | 30 | 1 | 5 | 10 | 6 | |
1.91 € | 1 | Available |
Same day
Stock | 10 | 6 | 40 | 1 | 5 | 10 | 6 | |
1.41 € | 1 | Available |
Same day
Stock | 10 | 8 | 12 | 1.25 | 6 | 13 | 8 | |
1.69 € | 1 | Available |
Same day
Stock | 10 | 8 | 20 | 1.25 | 6 | 13 | 8 | |
1.87 € | 1 | Available |
Same day
Stock | 10 | 8 | 30 | 1.25 | 6 | 13 | 8 | |
1.97 € | 1 | Available |
Same day
Stock | 10 | 8 | 35 | 1.25 | 6 | 13 | 8 | |
1.79 € | 1 | Available | 5 Days | 10 | 8 | 40 | 1.25 | 6 | 13 | 8 |
Loading...
Basic information
| Detailed Shape | Standard | Material | Resin | Surface Treatment (Details) | NA |
|---|---|---|---|---|---|
| Mounting Hole Shape | Hex Socket | Additional Shapes | Standard | Thread ridge Type | Metric Coarse |
| Basic Shape | Standard (Round) | Sales Unit | Low Quantity (can be purchased from one) | Application | Standard |
| Plastic Material | PVC |
Configure
Stock
-
- Show only stock items
Basic Attributes
-
Nominal of Thread (M)
-
Length L or l (mm)
-
Pitch(mm)
-
B
-
D
-
H
-
Type
- PVC/CB
Filter by standard shipping days
-
- All
- Same day
- 5 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
