Recoil Tap
- Volume Discount
· Recoil taps differ from ordinary taps, designed for exclusive use with screw thread inserts (STI). They have a large diameter but the same pitch as a standard tap in order to accommodate the Recoil Inserts.
· Recoil Taps are manufactured to precise standards from High Speed steel (HSS or HSS-E) with ground threads and are available in Intermediate and Bottoming leads.
· In addition to hand taps, Spiral Point and Spiral Flute machine taps are also available for mass production purposes. In addition, for all spark plug applications pilot nose taps are available, which do not require a special recoil drill. The Recoil thread inserts when installed into a correctly tapped hole will provide the applicable internal thread tolerance for the installed bolt.
· Intermediate tap...The most commonly used tap, mainly used for through hole applications. 4 -thread lead.
· Bottoming tap...Used when tapping to the bottom of a blind hole. 2-Thread lead, and is normally used after a taper tap or intermediate tap.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 45025 |
| 45035 |
| 45045 |
| 45055 |
| 45056 |
| 45065 |
| 45066 |
| 45085 |
| 45086 |
| 45105 |
| 45106 |
| 45126 |
| 45165 |
| 45255 |
| 47105 |
| 47106 |
| 48105 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | Thread Diameter(Inserted)M (mm) | Screw Type for Tap | Pitch (mm) | Tapped | |
|---|---|---|---|---|---|---|---|---|---|
42.36 € | 1 | Available | 9 Days | 10 | 2 | Coarse | 0.4 | Medium Tapping | |
35.89 € | 1 | Available | 6 Days | 10 | 3 | Coarse | 0.5 | Medium Tapping | |
24.18 € | 1 | Available | 13 Days | 10 | 4 | Coarse | 0.7 | Medium Tapping | |
19.44 € | 1 | Available | 8 Days | 10 | 5 | Coarse | 0.8 | Medium Tapping | |
36.13 € | 1 | Available | 9 Days | 10 | 5 | Coarse | 0.8 | Upper Tapping | |
24.74 € | 1 | Available | 8 Days | 10 | 6 | Coarse | 1 | Medium Tapping | |
34.06 € | 1 | Available | 9 Days | 10 | 6 | Coarse | 1 | Upper Tapping | |
23.52 € | 1 | Available | 9 Days | 10 | 8 | Coarse | 1.25 | Medium Tapping | |
40.29 € | 1 | Available | 9 Days | 10 | 8 | Coarse | 1.25 | Upper Tapping | |
34.94 € | 1 | Available | 8 Days | 10 | 10 | Coarse | 1.5 | Medium Tapping | |
63.10 € | 1 | Available | 8 Days | 10 | 10 | Coarse | 1.5 | Upper Tapping | |
83.83 € | 1 | 9 Days | 10 | 12 | Coarse | 1.75 | Upper Tapping | ||
114.94 € | 1 | Available | 9 Days | 10 | 16 | Coarse | 2 | Medium Tapping | |
29.03 € | 1 | Available | 9 Days | 10 | 2.5 | Coarse | 0.45 | Medium Tapping | |
63.10 € | 1 | Available | 9 Days | 10 | 10 | Fine | 1.25 | Medium Tapping | |
67.24 € | 1 | Available | 9 Days | 10 | 10 | Fine | 1.25 | Upper Tapping | |
75.54 € | 1 | Available | 9 Days | 10 | 10 | Spark Plug | 1 | Medium Tapping |
Loading...
Basic information
| Type | Tool | Sales Unit | Low Quantity (can be purchased from one) | Application | Insertion |
|---|
Configure
Basic Attributes
-
Thread Diameter(Inserted)M(mm)
-
Screw Type for Tap
- Coarse
- Fine
- Spark Plug
-
Pitch(mm)
-
Tapped
- Medium Tapping
- Upper Tapping
-
Type
- 45□□□
- 47□□□
- 48□□□
Filter by standard shipping days
-
- All
- 6 Days or Less
- 8 Days or Less
- 9 Days or Less
- 13 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
