U-Shaped Strainer SU-10 Series
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| SU-10-125A |
| SU-10-150A |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Supply Side, Nominal Designation of Pipe Flange Denomination B(Denomination A) | Control Side Nominal The Pipe Flange B name(A name) | |
|---|---|---|---|---|---|---|
7,223.67 € | 1 | 10 Days | 5B(125A) | 5B(125A) | ||
9,303.03 € | 1 | 10 Days | 6B(150A) | 6B(150A) |
Loading...
Basic information
| Applicable Fluid | Water / Oil / Other | Shape | U Shaped | Body Material | Stainless Cast Steel |
|---|---|---|---|---|---|
| Supply Side, Connection Type | Flange | Control Side, Connection Type | Flange | Maximum Pressure(MPa) | 1.0 |
| Maximum Temperature(°C) | 220 | Strainer Screen(Mesh) | 60 | Connection flange | JIS 10K FF flange |
Configure
Basic Attributes
-
Supply Side, Nominal Designation of Pipe Flange Denomination B(Denomination A)
-
Control Side Nominal The Pipe Flange B name(A name)
-
Type
- SU-10
-
Filter by CAD data type
- 2D
Filter by standard shipping days
-
- All
- 10 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
