[Features]
· Made of stainless steel, with excellent corrosion resistance.
· Curled part is welded.
· Since the resin color is incorporated in the curled part, rotation is very smooth.
· Because it uses a stainless steel U nut, pins are not lost and can be reassigned.
· Ideal for medium size / small doors.
· Right-and-left type (pin recombination)

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Part Number
FB-1880-1
FB-1880-2A
Part Number
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?
Application Bores for Fixation Product Code

99.71 €

1 6 Days For Wing2-Hole61116

131.85 €

1 6 Days For Van4-Hole61120

Loading...

  1. 1

Basic information

Main Body Type Leaf type Length L *Figure in () is the min length of the adjustable type.(mm) 144 Material Stainless Steel Plate (EN 1.4301 Equiv.)
Surface Finish Electrolytic Polishing Width W(mm) 260 Plate Thickness t(mm) 4
Shaft Diameter φD(mm) 12 Mounting Hole Through Hole
