Flat plug-in hinges / conical countersinks / rolled / stainless steel / mirror polished / B-1268 / TAKIGEN
[Product Information]
· <Common items>
· Main body type: Detachable hinge
· Detachable, flag hinge type: Standard type
· Length L (mm): 60
· Material: Stainless steel plate (SUS304)
· Surface finish: Mirror surface buffing
· Width W (mm): 44
· Plate thickness t (mm): 1.5
· <Common items>
· Main body type: Detachable hinge
· Detachable, flag hinge type: Standard type
· Length L (mm): 60
· Material: Stainless steel plate (SUS304)
· Surface finish: Mirror surface buffing
· Width W (mm): 44
· Plate thickness t (mm): 1.5
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| B-1268-2-L |
| B-1268-2-R |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | Reversed | Product Code | |
|---|---|---|---|---|---|---|---|
42.05 € | 1 | 6 Days | 10 | Left Type | 13340 | ||
42.05 € | 1 | 6 Days | 10 | Right Type | 13341 |
Loading...
Basic information
| Main Body Type | Detachable Hinges | Detachable Flag Hinges Type | Standard Type | Length L *Figure in () is the min length of the adjustable type.(mm) | 60 |
|---|---|---|---|---|---|
| Material | Stainless Steel Plate (EN 1.4301 Equiv.) | Surface Finish | Mirror Buffed Surface | Width W(mm) | 44 |
| Plate Thickness t(mm) | 1.5 | Shaft Diameter φD(mm) | 5 | Mounting Hole | Through Hole |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
