Swivel Joints JL-DC Series
- Promotional pricing ends 30/11/2024
- Volume Discount
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| JL04DC |
| JL06DC |
| JL08DC |
| JL12DC |
| JL16DC |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Screw Size | Nominal Connection Screw Exhaust Side (Single unit, swivel) | |
|---|---|---|---|---|---|---|
85.33 € | 1 | 6 Days | 04(1/4B) | [1/4B] 04(1/4B) | ||
80.04 € 56.03 € | 1 | Available |
Same day
Stock | 06(3/8B) | [3/8B] 06(3/8B) | |
121.35 € | 1 | 5 Days | 08(1/2B) | [1/2B] 08(1/2B) | ||
127.53 € | 1 | 5 Days | 12(3/4B) | [3/4B] 12(3/4B) | ||
169.44 € | 1 | 36 Days | 16(1B) | [1B] 16(1B) |
Loading...
Basic information
| Fitting type | General Swivel | Applicable Fluids | Mineral operational oil | Maximum Operating Temperature(°C) | 100 |
|---|---|---|---|---|---|
| Max Operating Pressure(MPa) | 20.5 | Allowable Rotational Speed(r.p.m) | 10 | Connection Type | Thread-to-Thread, Connection |
| Housing Type for the Hose Side (Screw type) | Rc | Type of Shaft on Machine Side (Screw type) | R | O-Ring Material | NBR |
| Fitting Material | Steel | Surface Treatment | Zinc Plating · Chromate Treatment |
Configure
Stock
-
- Show only stock items
Basic Attributes
-
Screw Size
-
Nominal Connection Screw Exhaust Side (Single unit, swivel)
- 1/4B
- 3/8B
- 1/2B
- 3/4B
- 1B
- 1/4B
-
Type
- JL-DC
Filter by standard shipping days
-
- All
- Same day
- 5 Days or Less
- 6 Days or Less
- 36 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
