Flat Mounted Plate Type Castors 420E / 415E Wheel Diameter 40-75mm
- Volume Discount
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Mounting Height H or H1 and H2 (mm) | Load Range (daN) | Stopper | Allowable Load 1 piece (daN) | Wheel Material | Wheel Characteristics | Mounting Hole Pitch Longitudinal direction (X) (mm) | Mounting Hole Pitch Transverse Direction (Y) (mm) | Mounting Seat A (Plate Length) (mm) | Mounting Seat B (Plate Width) (mm) | Wheel Dia. D (mm) | Car width (mm) | Swivel Radius (mm) | Mounting Hole Diameter P (mm) | Eccentricity E or E1, E2 (mm) | Variety of Vehicles | Wheel configuration | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
17.44 € | 1 | 11 Days | 58 | ~35.00 | With Rotation Stopper | 30 | [Nylon] MC Nylon | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis) | 40 | 20 | 51 | 31 | 40 | 17 | 51 | 5.5 | 20.0 | MC | MC Nylon Integral Wheel | ||
19.81 € | 1 | 6 Days | 65 | 35.01~80.00 | With Rotation Stopper | 40 | [Nylon] MC Nylon | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis) | 56 | 28 | 70 | 42 | 50 | 20 | 58 | 6.5 | 21.0 | MC | MC Nylon Integral Wheel | ||
23.44 € | 1 | 11 Days | 82 | 35.01~80.00 | With Rotation Stopper | 40 | [Nylon] MC Nylon | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis) | 56 | 28 | 70 | 42 | 65 | 20 | 62 | 6.5 | 24.0 | MC | MC Nylon Integral Wheel | ||
29.30 € | 1 | 6 Days | 92 | 35.01~80.00 | With Rotation Stopper | 50 | [Nylon] MC Nylon | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis) | 56 | 28 | 70 | 42 | 75 | 20 | 68 | 6.5 | 29.0 | MC | MC Nylon Integral Wheel | ||
5.26 € | 1 | Available |
Same day
Stock | 58 | ~35.00 | With Rotation Stopper | 30 | [Nylon] Nylon | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis) | 40 | 20 | 51 | 31 | 40 | 16 | 51 | 5.5 | 20.0 | N | Nylon Integral Wheel | |
8.73 € | 1 |
Same day
Stock | 65 | 35.01~80.00 | With Rotation Stopper | 40 | [Nylon] Nylon | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis) | 56 | 28 | 70 | 42 | 50 | 21 | 58 | 6.5 | 21.0 | N | Nylon Integral Wheel | ||
10.07 € | 1 | 5 Days | 82 | 35.01~80.00 | With Rotation Stopper | 40 | [Nylon] Nylon | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis) | 56 | 28 | 70 | 42 | 65 | 21 | 62 | 6.5 | 24.0 | N | Nylon Integral Wheel | ||
11.46 € | 1 |
Same day
Stock | 92 | 35.01~80.00 | With Rotation Stopper | 50 | [Nylon] Nylon | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis) | 56 | 28 | 70 | 42 | 75 | 21 | 68 | 6.5 | 29.0 | N | Nylon Integral Wheel | ||
12.04 € | 1 | 11 Days | 82 | ~35.00 | With Rotation Stopper | 30 | Rubber | - | 56 | 28 | 70 | 42 | 65 | 20 | 62 | 6.5 | 24.0 | PR | Iron Plate Wheel Rubber Winding Wheel with Resin Bushing | ||
13.41 € | 1 | 6 Days | 92 | 35.01~80.00 | With Rotation Stopper | 40 | Rubber | - | 56 | 28 | 70 | 42 | 75 | 21 | 68 | 6.5 | 29.0 | PR | Iron Plate Wheel Rubber Winding Wheel with Resin Bushing | ||
5.64 € | 1 | Available |
Same day
Stock | 58 | ~35.00 | With Rotation Stopper | 25 | Rubber | - | 40 | 20 | 51 | 31 | 40 | 17 | 51 | 5.5 | 20.0 | R | Rubber Integrated Wheels Containing Resin Bush | |
7.57 € | 1 | Available |
Same day
Stock | 65 | ~35.00 | With Rotation Stopper | 30 | Rubber | - | 56 | 28 | 70 | 42 | 50 | 20 | 58 | 6.5 | 21.0 | R | Rubber Integrated Wheels Containing Resin Bush | |
12.46 € | 1 |
Same day
Stock | 82 | ~35.00 | With Rotation Stopper | 30 | Rubber | - | 56 | 28 | 70 | 42 | 65 | 21 | 62 | 6.5 | 24.0 | R | Rubber Integrated Wheels Containing Resin Bush | ||
14.25 € | 1 |
Same day
Stock | 92 | 35.01~80.00 | With Rotation Stopper | 40 | Rubber | - | 56 | 28 | 70 | 42 | 75 | 21 | 68 | 6.5 | 29.0 | R | Rubber Integrated Wheels Containing Resin Bush | ||
5.87 € | 1 | Available |
Same day
Stock | 58 | ~35.00 | With Rotation Stopper | 30 | Urethane | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) | 40 | 20 | 51 | 31 | 40 | 16 | 51 | 5.5 | 20.0 | UR | Nylon-Wheel Thermoplastic Urethane Foam Winding Wheel | |
11.44 € | 1 |
Same day
Stock | 65 | 35.01~80.00 | With Rotation Stopper | 40 | Urethane | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) | 56 | 28 | 70 | 42 | 50 | 21 | 58 | 6.5 | 21.0 | UR | Nylon-Wheel Thermoplastic Urethane Foam Winding Wheel | ||
11.36 € | 1 | Available | 11 Days | 82 | 35.01~80.00 | With Rotation Stopper | 40 | Urethane | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) | 56 | 28 | 70 | 42 | 65 | 21 | 62 | 6.5 | 24.0 | UR | Nylon-Wheel Thermoplastic Urethane Foam Winding Wheel | |
12.78 € | 1 | Available |
Same day
Stock | 92 | 35.01~80.00 | With Rotation Stopper | 50 | Urethane | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) | 56 | 28 | 70 | 42 | 75 | 21 | 68 | 6.5 | 29.0 | UR | Nylon-Wheel Thermoplastic Urethane Foam Winding Wheel | |
16.42 € | 1 | 11 Days | 58 | ~35.00 | NA | 30 | [Nylon] MC Nylon | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis) | 40 | 20 | 51 | 31 | 40 | 17 | 41 | 5.5 | 20.0 | MC | MC Nylon Integral Wheel | ||
18.60 € | 1 | 11 Days | 65 | 35.01~80.00 | NA | 40 | [Nylon] MC Nylon | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis) | 56 | 28 | 70 | 42 | 50 | 20 | 47 | 6.5 | 21.0 | MC | MC Nylon Integral Wheel | ||
22.14 € | 1 | 11 Days | 82 | 35.01~80.00 | NA | 40 | [Nylon] MC Nylon | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis) | 56 | 28 | 70 | 42 | 65 | 20 | 58 | 6.5 | 24.0 | MC | MC Nylon Integral Wheel | ||
27.67 € | 1 | 11 Days | 92 | 35.01~80.00 | NA | 50 | [Nylon] MC Nylon | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis) | 56 | 28 | 70 | 42 | 75 | 20 | 68 | 6.5 | 29.0 | MC | MC Nylon Integral Wheel | ||
4.10 € | 1 | Available |
Same day
Stock | 58 | ~35.00 | NA | 30 | [Nylon] Nylon | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis) | 40 | 20 | 51 | 31 | 40 | 16 | 41 | 5.5 | 20.0 | N | Nylon Integral Wheel | |
6.88 € | 1 | 5 Days | 65 | 35.01~80.00 | NA | 40 | [Nylon] Nylon | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis) | 56 | 28 | 70 | 42 | 50 | 21 | 47 | 6.5 | 21.0 | N | Nylon Integral Wheel | ||
8.62 € | 1 | 12 Days | 82 | 35.01~80.00 | NA | 40 | [Nylon] Nylon | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis) | 56 | 28 | 70 | 42 | 65 | 21 | 58 | 6.5 | 24.0 | N | Nylon Integral Wheel | ||
9.63 € | 1 | 5 Days | 92 | 35.01~80.00 | NA | 50 | [Nylon] Nylon | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) / Chemical Resistance (Weak Acids/Alkalis) | 56 | 28 | 70 | 42 | 75 | 21 | 68 | 6.5 | 29.0 | N | Nylon Integral Wheel | ||
11.24 € | 1 | 11 Days | 82 | ~35.00 | NA | 30 | Rubber | - | 56 | 28 | 70 | 42 | 65 | 20 | 58 | 6.5 | 24.0 | PR | Iron Plate Wheel Rubber Winding Wheel with Resin Bushing | ||
12.22 € | 1 | 11 Days | 92 | 35.01~80.00 | NA | 40 | Rubber | - | 56 | 28 | 70 | 42 | 75 | 21 | 68 | 6.5 | 29.0 | PR | Iron Plate Wheel Rubber Winding Wheel with Resin Bushing | ||
4.59 € | 1 | Available |
Same day
Stock | 58 | ~35.00 | NA | 25 | Rubber | - | 40 | 20 | 51 | 31 | 40 | 17 | 41 | 5.5 | 20.0 | R | Rubber Integrated Wheels Containing Resin Bush | |
8.37 € | 1 |
Same day
Stock | 65 | ~35.00 | NA | 30 | Rubber | - | 56 | 28 | 70 | 42 | 50 | 20 | 47 | 6.5 | 21.0 | R | Rubber Integrated Wheels Containing Resin Bush | ||
10.47 € | 1 | 5 Days | 82 | ~35.00 | NA | 30 | Rubber | - | 56 | 28 | 70 | 42 | 65 | 21 | 58 | 6.5 | 24.0 | R | Rubber Integrated Wheels Containing Resin Bush | ||
12.71 € | 1 |
Same day
Stock | 92 | 35.01~80.00 | NA | 40 | Rubber | - | 56 | 28 | 70 | 42 | 75 | 21 | 68 | 6.5 | 29.0 | R | Rubber Integrated Wheels Containing Resin Bush | ||
4.91 € | 1 | Available |
Same day
Stock | 58 | ~35.00 | NA | 30 | Urethane | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) | 40 | 20 | 51 | 31 | 40 | 16 | 41 | 5.5 | 20.0 | UR | Nylon-Wheel Thermoplastic Urethane Foam Winding Wheel | |
9.97 € | 1 |
Same day
Stock | 65 | 35.01~80.00 | NA | 40 | Urethane | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) | 56 | 28 | 70 | 42 | 50 | 21 | 47 | 6.5 | 21.0 | UR | Nylon-Wheel Thermoplastic Urethane Foam Winding Wheel | ||
10.26 € | 1 | Available | 11 Days | 82 | 35.01~80.00 | NA | 40 | Urethane | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) | 56 | 28 | 70 | 42 | 65 | 21 | 58 | 6.5 | 24.0 | UR | Nylon-Wheel Thermoplastic Urethane Foam Winding Wheel | |
10.99 € | 1 | Available | 6 Days | 92 | 35.01~80.00 | NA | 50 | Urethane | Abrasion Resistance / Gasoline Resistance / Oil Resistance (Machine Oil) | 56 | 28 | 70 | 42 | 75 | 21 | 68 | 6.5 | 29.0 | UR | Nylon-Wheel Thermoplastic Urethane Foam Winding Wheel |
Loading...
Basic information
| Caster Type | Swiveling Direct Mount Plate | Fitting Material | Steel | Mounting Hole Type | Round Hole |
|---|---|---|---|---|---|
| Load Category | Light Load | (Metal Fitting/Main Body) Processing - Finish | Chrome Plating Finish | Swiveling/Fixed | Swiveling |
| Part Number | E |
Configure
Stock
-
- Show only stock items
Basic Attributes
-
Mounting Height H or H1 and H2(mm)
-
Load Range(daN)
- ~35.00
- 35.01~80.00
-
Stopper
- NA
- With Rotation Stopper
-
Allowable Load 1 piece(daN)
-
Wheel Material
- Rubber
- Nylon
- Urethane
-
Wheel Characteristics
- Abrasion Resistance
- Gasoline Resistance
- Oil Resistance (Machine Oil)
- Chemical Resistance (Weak Acids/Alkalis)
-
Mounting Hole Pitch Longitudinal direction (X)(mm)
-
Mounting Hole Pitch Transverse Direction (Y)(mm)
-
Mounting Seat A (Plate Length)(mm)
-
Mounting Seat B (Plate Width)(mm)
-
Wheel Dia. D(mm)
-
Car width(mm)
-
Swivel Radius(mm)
-
Mounting Hole Diameter P(mm)
-
Eccentricity E or E1, E2(mm)
-
Variety of Vehicles
-
Type
- 415E
- 420E
-
Filter by CAD data type
- 2D
- 3D
Filter by standard shipping days
-
- All
- Same day
- 5 Days or Less
- 6 Days or Less
- 11 Days or Less
- 12 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
