Set collars / stainless steel, steel / wedge clamping / double cross hole / SCK-P2
- Promotional pricing ends 30/11/2024
- Volume Discount
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | I.D. B (mm) | Outer Diameter D (mm) | Material | Surface Treatment Applied or Not | Material | Surface Treatment | |
|---|---|---|---|---|---|---|---|---|---|---|---|
12.95 € | 1 | 6 Days | 10 | 10 | 35 | Iron | Surface Treatment | Steel | Black Oxide | ||
18.88 € | 1 | 6 Days | 10 | 10 | 35 | Stainless Steel | No Surface Treatment | Stainless Steel | NA | ||
12.70 € 8.89 € | 1 | Available |
Same day
Stock | 10 | 12 | 38 | Iron | Surface Treatment | Steel | Black Oxide | |
18.88 € | 1 | 6 Days | 10 | 12 | 38 | Stainless Steel | No Surface Treatment | Stainless Steel | NA | ||
14.27 € | 1 | 6 Days | 10 | 15 | 40 | Iron | Surface Treatment | Steel | Black Oxide | ||
20.18 € | 1 | 6 Days | 10 | 15 | 40 | Stainless Steel | No Surface Treatment | Stainless Steel | NA | ||
14.27 € | 1 | 9 Days | 10 | 16 | 42 | Iron | Surface Treatment | Steel | Black Oxide | ||
20.18 € | 1 | 6 Days | 10 | 16 | 42 | Stainless Steel | No Surface Treatment | Stainless Steel | NA | ||
15.59 € | 1 | 9 Days | 10 | 20 | 46 | Iron | Surface Treatment | Steel | Black Oxide | ||
24.17 € | 1 | 6 Days | 10 | 20 | 46 | Stainless Steel | No Surface Treatment | Stainless Steel | NA | ||
16.26 € 11.38 € | 1 | Available |
Same day
Stock | 10 | 25 | 50 | Iron | Surface Treatment | Steel | Black Oxide | |
26.70 € | 1 | 6 Days | 10 | 25 | 50 | Stainless Steel | No Surface Treatment | Stainless Steel | NA | ||
18.25 € | 1 | 6 Days | 10 | 30 | 56 | Iron | Surface Treatment | Steel | Black Oxide | ||
32.03 € | 1 | Available | 6 Days | 10 | 30 | 56 | Stainless Steel | No Surface Treatment | Stainless Steel | NA | |
20.79 € | 1 | 6 Days | 10 | 35 | 65 | Iron | Surface Treatment | Steel | Black Oxide | ||
38.66 € | 1 | 6 Days | 10 | 35 | 65 | Stainless Steel | No Surface Treatment | Stainless Steel | NA | ||
22.84 € | 1 | 6 Days | 10 | 40 | 70 | Iron | Surface Treatment | Steel | Black Oxide | ||
50.50 € | 1 | 6 Days | 10 | 40 | 70 | Stainless Steel | No Surface Treatment | Stainless Steel | NA | ||
29.37 € | 1 | 6 Days | 10 | 50 | 85 | Iron | Surface Treatment | Steel | Black Oxide | ||
64.99 € | 1 | 6 Days | 10 | 50 | 85 | Stainless Steel | No Surface Treatment | Stainless Steel | NA |
Loading...
Basic information
| Tightening Method | Wedge | Specifications | With side mounting hole | Thickness | Standard Type |
|---|---|---|---|---|---|
| Side Surface Machining | 2-Hole |
Configure
Stock
-
- Show only stock items
Basic Attributes
-
I.D. B(mm)
-
Outer Diameter D(mm)
-
Material
- Iron
- Stainless Steel
-
Surface Treatment Applied or Not
- No Surface Treatment
- Surface Treatment
-
Material
- Stainless Steel
- Steel
-
Surface Treatment
- Black Oxide
- NA
-
Type
- SCK
-
Filter by CAD data type
- 2D
- 3D
Filter by standard shipping days
-
- All
- Same day
- 6 Days or Less
- 9 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
