TWIN FU-NUT
- Volume Discount
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| TFU02SC-15-S45C |
| TFU03SC-17-S45C |
| TFU04SC-20-S45C |
| TFU05SC-25-S45C |
| TFU06SC-30-S45C |
| TFU07SC-35-S45C |
| TFU08SC-40-S45C |
| TFU09SC-45-S45C |
| TFU10SC-50-S45C |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | Thread Nominal M | Pitch (p) | |
|---|---|---|---|---|---|---|---|
21.96 € | 1 | 6 Days | 10 | M15 | 1 | ||
21.09 € | 1 | 6 Days | 10 | M17 | 1 | ||
22.07 € | 1 | 6 Days | 10 | M20 | 1 | ||
25.01 € | 1 | 6 Days | 10 | M25 | 1.5 | ||
25.83 € | 1 | 6 Days | 10 | M30 | 1.5 | ||
26.28 € | 1 | 6 Days | 10 | M35 | 1.5 | ||
27.01 € | 1 | Available |
Same day
Stock | 10 | M40 | 1.5 | |
33.35 € | 1 | 6 Days | 10 | M45 | 1.5 | ||
39.20 € | 1 | 8 Days | 10 | M50 | 1.5 |
Loading...
Basic information
| Type | Lock Nut | Shape | Round shape | Material | Steel |
|---|---|---|---|---|---|
| Surface Treatment | Zinc Phosphate Coating Treatment | Screw Type | Metric (fine) Thread |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
