Compact Safety Door Switch
- Promotional pricing
[Features]
· As regards the contact structure, in addition of the conventional 1NC/1NO, 2NC, three type of 2NC/1NO, 3NC are available.
· M12 connector type easy to replace and saving man-hours is also released.
· Standardized au clad contact with high contact reliability.
· Supports both i.e. general load and micro load.
· Metallic head variation
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| D4NS-1BF |
| D4NS-1CF |
| D4NS-1DF |
| D4NS-2AF |
| D4NS-2BF |
| D4NS-2DF |
| D4NS-4BF |
| D4NS-8AF |
| D4NS-8BF |
| D4NS-8CF |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Main Body External Shape Width W (mm) | Main Body External Shape Height H (mm) | Main Body External Shape Depth D (mm) | Conduit size | Details Type | Contact format | |
|---|---|---|---|---|---|---|---|---|---|---|
25.83 € 20.41 € | 1 |
Same day
Stock | 31 | 30.6 | 96 | Pg13.5 | 1 Conduit Shape | 2NC | ||
38.83 € | 1 | 7 Days | 31 | 30.6 | 96 | Pg13.5 | 1 Conduit Shape | 2NC/1NO | ||
39.92 € | 1 | 7 Days | 31 | 30.6 | 96 | Pg13.5 | 1 Conduit Shape | 3NC | ||
36.35 € 22.90 € | 1 |
Same day
Stock | 31 | 30.6 | 96 | G1/2 | 1 Conduit Shape | 1NC/1NO | ||
36.35 € 22.90 € | 1 |
Same day
Stock | 31 | 30.6 | 96 | G1/2 | 1 Conduit Shape | 2NC | ||
40.55 € | 1 | 6 Days | 31 | 30.6 | 96 | G1/2 | 1 Conduit Shape | 3NC | ||
34.35 € | 1 | 7 Days | 31 | 30.6 | 96 | M20 | 1 Conduit Shape | 2NC | ||
39.78 € | 1 | 7 Days | 56 | 31.5 | 88 | M20 | 2 Conduit Shape | 1NC/1NO | ||
39.78 € | 1 | 7 Days | 56 | 31.5 | 88 | M20 | 2 Conduit Shape | 2NC | ||
45.52 € | 1 | 7 Days | 56 | 31.5 | 88 | M20 | 2 Conduit Shape | 2NC/1NO |
Loading...
Basic information
| Detector Shape | Key | Main Body Size | Small Size | Environment | Standard / Cold Resistance |
|---|---|---|---|---|---|
| Operating Temperature Range(°C) | -30::70 | Acquisition of Standard Approval | UL / GB(CCC) / EN | Protective Structure | IP67 |
| Force necessary for press side, O.F.(N) | 15 | Movement up to switching, P.T.(mm) | 6±3 | Maximum stroke T.T(mm) | 28 |
| Contact type | Mutual insulation double-throw | Mechanical Life(x10K times) | 100 | Operation Frequency of Machine(times/min. or Less) | 30 |
| Rated Operating Voltage(V) | 125 V DC / 250 V DC | Rated Current(A) | 2.5 | Operating Position OP(mm) | 10 |
| Direction of Operation | 4-direction mounting supported (front direction at shipment) / plastic |
