Pin stroke shape/Spring Plungers Type / With Stopper | Cylindrical Type | Drip Proofing Type | [Stainless Steel] Stainless Steel (EN 1.4029 Equiv.) | 0.5 | 8 | - | 0.25 | 0.8 | - | IP44 | NA | Discrete Wire | - | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Cylindrical Type | Drip Proofing Type | [Stainless Steel] Stainless Steel (EN 1.4029 Equiv.) | 0.5 | 8 | - | 0.25 | 0.8 | - | IP44 | Included | Discrete Wire | - | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Cylindrical Type | Drip Proofing Type | [Stainless Steel] Stainless Steel (EN 1.4029 Equiv.) | 0.5 | 8 | - | 0.25 | 0.8 | - | IP44 | NA | Cab Tire | - | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Cylindrical Type | Drip Proofing Type | [Stainless Steel] Stainless Steel (EN 1.4029 Equiv.) | 0.5 | 8 | - | 0.25 | 0.8 | - | IP44 | Included | Cab Tire | - | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Cylindrical Type / Flange | Drip Proofing Type | [Stainless Steel] Stainless Steel (EN 1.4029 Equiv.) | 0.5 | 8 | - | 0.25 | 0.8 | - | IP44 | NA | Discrete Wire | 10 | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Cylindrical Type / Flange | Drip Proofing Type | [Stainless Steel] Stainless Steel (EN 1.4029 Equiv.) | 0.5 | 8 | - | 0.25 | 0.8 | - | IP44 | Included | Discrete Wire | 10 | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Cylindrical Type / Flange | Drip Proofing Type | [Stainless Steel] Stainless Steel (EN 1.4029 Equiv.) | 0.5 | 8 | - | 0.25 | 0.8 | - | IP44 | NA | Cab Tire | 10 | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Cylindrical Type / Flange | Drip Proofing Type | [Stainless Steel] Stainless Steel (EN 1.4029 Equiv.) | 0.5 | 8 | - | 0.25 | 0.8 | - | IP44 | Included | Cab Tire | 10 | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Bolt Type | Drip Proofing Type | [Stainless Steel] Stainless Steel (EN 1.4029 Equiv.) | 0.5 | - | M10×0.75 | 0.25 | 0.8 | - | IP44 | NA | Discrete Wire | - | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Bolt Type | Drip Proofing Type | [Stainless Steel] Stainless Steel (EN 1.4029 Equiv.) | 0.5 | - | M10×0.75 | 0.25 | 0.8 | - | IP44 | Included | Discrete Wire | - | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Bolt Type | Drip Proofing Type | [Stainless Steel] Stainless Steel (EN 1.4029 Equiv.) | 0.5 | - | M10×0.75 | 0.25 | 0.8 | - | IP44 | NA | Cab Tire | - | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Bolt Type | Drip Proofing Type | [Stainless Steel] Stainless Steel (EN 1.4029 Equiv.) | 0.5 | - | M10×0.75 | 0.25 | 0.8 | - | IP44 | Included | Cab Tire | - | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Bolt Type / Flange | Drip Proofing Type | [Stainless Steel] Stainless Steel (EN 1.4029 Equiv.) | 0.5 | - | M10 x 1.5 | 0.25 | 0.8 | - | IP44 | NA | Discrete Wire | 13 | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Bolt Type / Flange | Drip Proofing Type | [Stainless Steel] Stainless Steel (EN 1.4029 Equiv.) | 0.5 | - | M10 x 1.5 | 0.25 | 0.8 | - | IP44 | Included | Discrete Wire | 13 | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Bolt Type / Flange | Drip Proofing Type | [Stainless Steel] Stainless Steel (EN 1.4029 Equiv.) | 0.5 | - | M10 x 1.5 | 0.25 | 0.8 | - | IP44 | NA | Cab Tire | 13 | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Bolt Type / Flange | Drip Proofing Type | [Stainless Steel] Stainless Steel (EN 1.4029 Equiv.) | 0.5 | - | M10 x 1.5 | 0.25 | 0.8 | - | IP44 | Included | Cab Tire | 13 | For linear hit | 10 | 1 pieces |
Ball contact / Ball plunger type / Wide Contact Angle / With Stopper | Bolt Type | Drip Proofing Type | - | 0.5 | - | M10×0.75 | 0.25 | 0.8 | [Up to Ø4] S Ø3 | IP44 | NA | Discrete Wire | - | Declined hit | 10 | 1 pieces |
Ball contact / Ball plunger type / Wide Contact Angle / With Stopper | Bolt Type | Drip Proofing Type | - | 0.5 | - | M10×0.75 | 0.25 | 0.8 | [Up to Ø4] S Ø3 | IP44 | Included | Discrete Wire | - | Declined hit | 10 | 1 pieces |
Ball contact / Ball plunger type / Wide Contact Angle / With Stopper | Bolt Type | Drip Proofing Type | - | 0.5 | - | M10×0.75 | 0.25 | 0.8 | [Up to Ø4] S Ø3 | IP44 | NA | Cab Tire | - | Declined hit | 10 | 1 pieces |
Ball contact / Ball plunger type / Wide Contact Angle / With Stopper | Bolt Type | Drip Proofing Type | - | 0.5 | - | M10×0.75 | 0.25 | 0.8 | [Up to Ø4] S Ø3 | IP44 | Included | Cab Tire | - | Declined hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Cylindrical Type | Waterproof Type | - | 0.3 | 9 | - | 0.15 | 1 | [Up to Ø2] Ø2 | IP67 | NA | Cab Tire | - | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Cylindrical Type | Waterproof Type | - | 0.3 | 9 | - | 0.15 | 1 | [Up to Ø2] Ø2 | IP67 | Included | Cab Tire | - | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Cylindrical Type / Flange | Waterproof Type | - | 0.3 | 11.5 | - | 0.15 | 1 | [Up to Ø2] Ø2 | IP67 | NA | Discrete Wire | 11 | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Cylindrical Type / Flange | Waterproof Type | - | 0.3 | 11.5 | - | 0.15 | 1 | [Up to Ø2] Ø2 | IP67 | Included | Discrete Wire | 11 | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Bolt Type | Waterproof Type | [Stainless Steel] Stainless Steel (EN 1.4029 Equiv.) | 0.3 | - | M10×0.75 | 0.15 | 1 | [Up to Ø2] Ø2 | IP67 | NA | Discrete Wire | - | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Bolt Type | Waterproof Type | [Stainless Steel] Stainless Steel (EN 1.4029 Equiv.) | 0.3 | - | M10×0.75 | 0.15 | 1 | [Up to Ø2] Ø2 | IP67 | Included | Discrete Wire | - | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Bolt Type | Waterproof Type | [Stainless Steel] Stainless Steel (EN 1.4029 Equiv.) | 0.3 | - | M10×0.75 | 0.15 | 1 | [Up to Ø2] Ø2 | IP67 | NA | Cab Tire | - | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Bolt Type | Waterproof Type | [Stainless Steel] Stainless Steel (EN 1.4029 Equiv.) | 0.3 | - | M10×0.75 | 0.15 | 1 | [Up to Ø2] Ø2 | IP67 | Included | Cab Tire | - | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Bolt Type / Flange | Waterproof Type | [Stainless Steel] Stainless Steel (EN 1.4029 Equiv.) | 0.3 | - | M10 x 1.5 | 0.15 | 1 | [Up to Ø2] Ø2 | IP67 | NA | Discrete Wire | 13 | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Bolt Type / Flange | Waterproof Type | [Stainless Steel] Stainless Steel (EN 1.4029 Equiv.) | 0.3 | - | M10 x 1.5 | 0.15 | 1 | [Up to Ø2] Ø2 | IP67 | Included | Discrete Wire | 13 | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Bolt Type / Flange | Waterproof Type | [Stainless Steel] Stainless Steel (EN 1.4029 Equiv.) | 0.3 | - | M10 x 1.5 | 0.15 | 1 | [Up to Ø2] Ø2 | IP67 | NA | Cab Tire | 13 | For linear hit | 10 | 1 pieces |
Pin stroke shape/Spring Plungers Type / With Stopper | Bolt Type / Flange | Waterproof Type | [Stainless Steel] Stainless Steel (EN 1.4029 Equiv.) | 0.3 | - | M10 x 1.5 | 0.15 | 1 | [Up to Ø2] Ø2 | IP67 | Included | Cab Tire | 13 | For linear hit | 10 | 1 pieces |
Ball contact / Ball plunger type / Wide Contact Angle / With Stopper | Cylindrical Type | Drip Proofing Type | - | 0.5 | 8 | - | 0.25 | 0.8 | [Up to Ø4] S Ø3 | IP44 | NA | Discrete Wire | - | Declined hit | 10 | 1 pieces |
Ball contact / Ball plunger type / Wide Contact Angle / With Stopper | Cylindrical Type | Drip Proofing Type | - | 0.5 | 8 | - | 0.25 | 0.8 | [Up to Ø4] S Ø3 | IP44 | Included | Discrete Wire | - | Declined hit | 10 | 1 pieces |
Ball contact / Ball plunger type / Wide Contact Angle / With Stopper | Cylindrical Type | Drip Proofing Type | - | 0.5 | 8 | - | 0.25 | 0.8 | [Up to Ø4] S Ø3 | IP44 | NA | Cab Tire | - | Declined hit | 10 | 1 pieces |
Ball contact / Ball plunger type / Wide Contact Angle / With Stopper | Cylindrical Type | Drip Proofing Type | - | 0.5 | 8 | - | 0.25 | 0.8 | [Up to Ø4] S Ø3 | IP44 | Included | Cab Tire | - | Declined hit | 10 | 1 pieces |
