CS-Touch Switch CSM
- Volume Discount
· Rectangular
· Can be fitted in confined spaces or small equipment
· Long strokes (1.5 mm).
· Contradictory to the switch with attached stopper mini STM, the stroke end does not have a stopper function.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| CSM105CA |
| CSM105CA-L |
| CSM105WA |
| CSM105WA-L |
| CSMP105CA |
| CSMP105CA-L |
| CSMP105WA |
| CSMP105WA-L |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | Environment | Contact Part O.D. | Protection Structure | LED | Cord | |
|---|---|---|---|---|---|---|---|---|---|---|
52.46 € | 1 | 5 Days | 10 | Standard | [Up to Ø4] Ø3.5 | IP65 | No | Cab Tire | ||
57.07 € | 1 | 5 Days | 10 | Standard | [Up to Ø4] Ø3.5 | IP65 | Provided | Cab Tire | ||
51.21 € | 1 | Available | 5 Days | 10 | Standard | [Up to Ø4] Ø3.5 | IP65 | No | Loose Wire | |
55.99 € | 1 | 13 Days | 10 | Standard | [Up to Ø4] Ø3.5 | IP65 | Provided | Loose Wire | ||
51.90 € | 1 | 5 Days | 10 | Waterproof Type | [Up to Ø2] Ø2 | IP67 | No | Cab Tire | ||
61.52 € | 1 | 5 Days | 10 | Waterproof Type | [Up to Ø2] Ø2 | IP67 | Provided | Cab Tire | ||
55.99 € | 1 | 13 Days | 10 | Waterproof Type | [Up to Ø2] Ø2 | IP67 | No | Loose Wire | ||
60.77 € | 1 | 13 Days | 10 | Waterproof Type | [Up to Ø2] Ø2 | IP67 | Provided | Loose Wire |
Loading...
Basic information
| Type | Pin stroke shape/Spring Plungers Type | Main Body Shape | Bolt Type | Contact Section Type | R Contact |
|---|---|---|---|---|---|
| Body Material | Stainless Steel (EN 1.4305 Equiv.) | Contact Material | JIS-SUS HRC50 | Contact Stroke S(mm) | 1.5 |
| Contact Point Type | Contact type NO | Mounting Screw Nominal M | M10×0.5 | Operating Temperature Range(°C) | 0::80 |
| Switch Operating Point P(mm) | 0.3 | Repeatability | 0.003mm | Contact Force, Push Direction(N) | 1 |
| Mechanical Life(x 10K times) | 1000 |
Configure
Basic Attributes
-
Environment
- Standard
- Waterproof Type
-
Contact Part O.D.
- Up to Ø2
- Up to Ø4
- Up to Ø2
-
LED
- No
- Provided
-
Cord
- Cab Tire
- Loose Wire
-
Type
- CSM
- CSMP
-
Filter by CAD data type
- 2D
Filter by standard shipping days
-
- All
- 5 Days or Less
- 13 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
