CK Fittings - Screw-in Type Malleable Cast Iron Pipe Fitting - Cap
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Thread Nominal M1 | Applicable Fluid | Surface Treatment | |
|---|---|---|---|---|---|---|---|
4.82 € | 1 | Available | 8 Days | 1/4B(8A) | Water / Air / Vapor / Gas / Oil | NA | |
4.12 € | 1 | Available | 8 Days | 1/4B(8A) | Water / Air / Gas / Oil | Zinc Plating | |
4.82 € | 1 | Available | 8 Days | 3/8B(10A) | Water / Air / Vapor / Gas / Oil | NA | |
4.12 € | 1 | 8 Days | 3/8B(10A) | Water / Air / Gas / Oil | Zinc Plating | ||
3.69 € | 1 | Available | 8 Days | 1/2B(15A) | Water / Air / Vapor / Gas / Oil | NA | |
10.26 € | 1 | 8 Days | 1/2B(15A) | Water | Resin Coating | ||
3.77 € | 1 | Available | 8 Days | 1/2B(15A) | Water / Air / Gas / Oil | Zinc Plating | |
5.04 € | 1 | 8 Days | 3/4B(20A) | Water / Air / Vapor / Gas / Oil | NA | ||
11.84 € | 1 | 8 Days | 3/4B(20A) | Water | Resin Coating | ||
5.04 € | 1 | Available | 8 Days | 3/4B(20A) | Water / Air / Gas / Oil | Zinc Plating | |
6.30 € | 1 | 8 Days | 1B(25A) | Water / Air / Vapor / Gas / Oil | NA | ||
15.02 € | 1 | 8 Days | 1B(25A) | Water | Resin Coating | ||
6.30 € | 1 | Available | 5 Days | 1B(25A) | Water / Air / Gas / Oil | Zinc Plating | |
9.15 € | 1 | 8 Days | 1 1/4B(32A) | Water / Air / Vapor / Gas / Oil | NA | ||
20.04 € | 1 | 8 Days | 1 1/4B(32A) | Water | Resin Coating | ||
7.83 € | 1 | 8 Days | 1 1/4B(32A) | Water / Air / Gas / Oil | Zinc Plating | ||
10.57 € | 1 | 8 Days | 1 1/2B(40A) | Water / Air / Vapor / Gas / Oil | NA | ||
25.12 € | 1 | 8 Days | 1 1/2B(40A) | Water | Resin Coating | ||
9.06 € | 1 | 8 Days | 1 1/2B(40A) | Water / Air / Gas / Oil | Zinc Plating | ||
11.72 € | 1 | 8 Days | 2B(50A) | Water / Air / Vapor / Gas / Oil | NA | ||
34.53 € | 1 | 8 Days | 2B(50A) | Water | Resin Coating | ||
12.17 € | 1 | 8 Days | 2B(50A) | Water / Air / Gas / Oil | Zinc Plating | ||
24.03 € | 1 | 8 Days | 2 1/2B(65A) | Water / Air / Vapor / Gas / Oil | NA | ||
50.16 € | 1 | 8 Days | 2 1/2B(65A) | Water | Resin Coating | ||
24.03 € | 1 | 8 Days | 2 1/2B(65A) | Water / Air / Gas / Oil | Zinc Plating | ||
33.61 € | 1 | 8 Days | 3B(80A) | Water / Air / Vapor / Gas / Oil | NA | ||
63.77 € | 1 | 8 Days | 3B(80A) | Water | Resin Coating | ||
33.61 € | 1 | 8 Days | 3B(80A) | Water / Air / Gas / Oil | Zinc Plating | ||
72.86 € | 1 | 8 Days | 4B(100A) | Water / Air / Vapor / Gas / Oil | NA | ||
89.03 € | 1 | 8 Days | 4B(100A) | Water | Resin Coating | ||
72.86 € | 1 | 8 Days | 4B(100A) | Water / Air / Gas / Oil | Zinc Plating | ||
102.35 € | 1 | 8 Days | 5B(125A) | Water / Air / Vapor / Gas / Oil | NA | ||
162.71 € | 1 | 8 Days | 5B(125A) | Water | Resin Coating | ||
102.35 € | 1 | 8 Days | 5B(125A) | Water / Air / Gas / Oil | Zinc Plating | ||
142.32 € | 1 | 8 Days | 6B(150A) | Water / Air / Vapor / Gas / Oil | NA | ||
208.03 € | 1 | 8 Days | 6B(150A) | Water | Resin Coating | ||
142.49 € | 1 | 8 Days | 6B(150A) | Water / Air / Gas / Oil | Zinc Plating |
Loading...
Basic information
| Type | Fitting | Connection Type | Pitch (Terminal) | Connecting Shape | Cap |
|---|---|---|---|---|---|
| Material | Cast Iron | Connection Thread Type M1 | Rc | Max. Operating Pressure(MPa) | 2.5 |
| Divisions of Max. Operating Pressure | More than 2.0MPa | Interior Resin Lining | NA |
Configure
Basic Attributes
-
Thread Nominal M1
- 1/4B(8A)
- 3/8B(10A)
- 1/2B(15A)
- 3/4B(20A)
- 1B(25A)
- 1 1/4B(32A)
- 1 1/2B(40A)
- 2B(50A)
- 2 1/2B(65A)
- 3B(80A)
- 4B(100A)
- 5B(125A)
- 6B(150A)
-
Applicable Fluid
- Water
- Air
- Vapor
- Gas
- Oil
-
Surface Treatment
- NA
- Zinc Plating
- Resin Coating
-
Type
- CA
Filter by standard shipping days
-
- All
- 5 Days or Less
- 8 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
