L Shaped Hook Nail (Stainless Steel)【2-17 Pieces Per Package】
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| TYKS16 |
| TYKS20 |
| TYKS22 |
| TYKS25 |
| TYKS28 |
| TYKS32 |
| TYKS35 |
| TYKS38 |
| TYKS45 |
| TYKS50 |
| Part Number |
Standard Unit Price
| Number of pc(s). included in pkg. | Minimum order quantity | Volume Discount | A (mm) | D (mm) | S (mm) | Load Resistance (kg) | Wire diameter (mm) | Quantity (piece) | JAN Code | Order Code | Mass (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
10.21 € | 17 Pieces Per Package | 1 pack | 6 Days | 10.5 | 16 | 9.5 | 1.2 | 2.20 | 17 (1 Package) | 4989999270037 | 275-7125 | 21( 17 Holes) | ||
10.21 € | 15 Pieces Per Package | 1 pack | 6 Days | 12.5 | 20 | 11.0 | 1.8 | 2.40 | 15 (1 Package) | 4989999270044 | 275-7133 | 23( 15 Holes) | ||
10.21 € | 14 Pieces Per Package | 1 pack | 6 Days | 14.0 | 22 | 11.0 | 1.8 | 2.40 | 14 (1 Package) | 4989999270051 | 275-7141 | 27( 14 Holes) | ||
10.21 € | 11 Pieces Per Package | 1 pack | 6 Days | 14.5 | 25 | 14.0 | 3.0 | 2.80 | 11 (1 Package) | 4989999270068 | 275-7150 | 29( 11 Holes) | ||
10.21 € | 9 Pieces Per Package | 1 pack | 6 Days | 15.5 | 28 | 16.0 | 3.5 | 3.10 | 9 (1 Package) | 4989999270075 | 275-7168 | 34( 9 Holes) | ||
10.21 € | 7 Pieces Per Package | 1 pack | 6 Days | 20 | 32 | 17.0 | 4.0 | 3.45 | 7 (1 Package) | 4989999270082 | 275-7176 | 34( 7 Holes) | ||
10.21 € | 5 Pieces Per Package | 1 pack | 6 Days | 21.0 | 35 | 18.0 | 4.5 | 3.90 | 5 (1 Package) | 4989999270099 | 275-7184 | 34( 5 Holes) | ||
10.21 € | 5 Pieces Per Package | 1 pack | 6 Days | 22.5 | 38 | 18.0 | 4.5 | 3.90 | 5 (1 Package) | 4989999270105 | 275-7192 | 34( 5 Holes) | ||
10.21 € | 3 Pieces Per Package | 1 pack | 6 Days | 25.0 | 45 | 22.0 | 5.0 | 4.20 | 3 (1 Package) | 4989999270112 | 275-7206 | 34( 3 Holes) | ||
10.21 € | 2 Pieces Per Package | 1 pack | 6 Days | 28.0 | 50 | 25.0 | 5.0 | 4.80 | 2 (1 Package) | 4989999270129 | 275-7214 | 30( 2 Holes) |
Loading...
Basic information
| Shape | Single Hook | Hook Material | Stainless Steel (EN 1.4301 Equiv.) | Fixing Method | Screw Type |
|---|
Configure
Basic Attributes
-
A(mm)
-
D(mm)
-
S(mm)
-
Load Resistance(kg)
-
Wire diameter(mm)
-
Quantity(piece)
-
JAN Code
-
Order Code
-
Type
- TYKS
Filter by standard shipping days
-
- All
- 6 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
