VU Fitting Sockets
- Volume Discount
• Lightweight exhaust water fitting that delivers excellent corrosion and chemical resistance. Internal stopper is for use with VU pipes.
[Application]
• For drainage and vent piping in housing complexes, detached houses, stores, and facilities.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| VUDS40 |
| VUDS50 |
| VUDS65 |
| VUDS75 |
| VUDS100 |
| VUDS125 |
| VUDS150 |
| VUDS200 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Applicable Pipe Outer Dia. D (D1) (Ø) | Nominal Diameter of PVC Pipe (mm) | L (mm) | Z (mm) | JAN Code | Order Code | Mass (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
1.54 € | 1 | Available | 6 Days | 48 | 40 | 47 | 3 | 4997983110078 | 446-6187 | 33 | |
1.98 € | 1 | Available | 6 Days | 60 | 50 | 53 | 3 | 4997983107382 | 446-6195 | 61 | |
3.38 € | 1 | Available | 6 Days | 76 | 65 | 73 | 3 | 4997983107399 | 446-6209 | 109 | |
5.18 € | 1 | Available | 6 Days | 89 | 75 | 84 | 4 | 4997983107405 | 446-6217 | 153 | |
10.01 € | 1 | 6 Days | 114 | 100 | 105 | 5 | 4997983107412 | 446-6144 | 300 | ||
19.47 € | 1 | Available | 6 Days | 140 | 125 | 135 | 5 | 4997983107429 | 446-6152 | 565 | |
33.15 € | 1 | 6 Days | 165 | 150 | 165 | 5 | 4997983107436 | 446-6161 | 925 | ||
46.81 € | 1 | Available | 6 Days | 216 | 200 | 215 | 5 | 4997983107443 | 446-6179 | 1347 |
Loading...
Basic information
| Type | Fitting | Material | Vinyl Chloride | Applicable Fluid | Water / Air |
|---|---|---|---|---|---|
| Connection Type | Pipe⇔Pipe, same diameters | Connection Type - Equal Diameter Tube | Socket | Material of Applicable Pipe | PVC |
| Surface Treatment | NA | Operating Temperature Range(°C) | 5::60 | Standard | AS-38 Standard, Some Manufacturer Standards |
| Number Contained In A Packet | 1 |
Configure
Basic Attributes
-
Applicable Pipe Outer Dia. D (D1)(Ø)
-
Nominal Diameter of PVC Pipe(mm)
-
L(mm)
-
Z(mm)
-
JAN Code
-
Order Code
-
Type
- VUDS
Filter by standard shipping days
-
- All
- 6 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
