KCM Roller Chain (JIS Standard Product)
· For transmission and driving of various equipment.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 25-1RP480L |
| 35-1RP320L |
| 60-1RP160L |
| 80-1RP120L |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Pitch | Chain No | Composition instructions | Roller Outer Diameter (mm) | Inner link internal width (mm) | Unit link (Qty.) | Tensile Strength (kN) | JANJ code | Order Code | Mass (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
35.81 € | 1 | 11 Days | 6.35 | 25 | 4.4 | 3.3 | 3.18 | 480 | 4.4 | 4560125570018 | 243-6973 | 130 | ||
34.25 € | 1 | 11 Days | 9.525 | 35 | 10.8 | 5.08 | 4.78 | 320 | 10.8 | 4560125570032 | 224-5850 | 330 | ||
75.52 € | 1 | 11 Days | 19.05 | 60 | 41.2 | 11.91 | 12.7 | 160 | 41.2 | 4560125570124 | 224-5949 | 1490 | ||
93.51 € | 1 | 11 Days | 25.4 | 80 | 72.6 | 15.88 | 15.88 | 120 | 72.6 | 4560125570148 | 224-5965 | 2500 |
Loading...
Basic information
| Type | Standard Chains | Number of Tracks | 1 | Material | Steel |
|---|---|---|---|---|---|
| Max. Allowable Tension(kN) | Up to 99 | Number of Columns | 1 | Pin Format | Joint link (rivet type) |
| Quantity(piece) | 1 |
Configure
Basic Attributes
-
Pitch
-
Chain No
-
Composition instructions
-
Roller Outer Diameter(mm)
- 3.3
- 5.08
- 11.91
- 15.88
-
Inner link internal width(mm)
-
Unit link(Qty.)
-
Tensile Strength(kN)
-
JANJ code
-
Order Code
-
Type
- 25
- 35
- 60
- 80
Filter by standard shipping days
-
- All
- 11 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
