Nylon Castors (Stainless Steel Hardware) Fixed
[Features]
· Uses (SUS304) stainless steel hardware and features the superior corrosion resistance and water resistance of a nylon wheel.
· Since the swivel part includes dust-proof and waterproof seals, the product can be used for long periods of time even in severe environments.
· Uses (SUS304) stainless steel hardware and features the superior corrosion resistance and water resistance of a nylon wheel.
· Since the swivel part includes dust-proof and waterproof seals, the product can be used for long periods of time even in severe environments.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| TP5140R-NYL-SUS |
| TP5150R-NYL-SUS |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Mounting Height H (mm) | Wheel Dia. D (mm) | Order Code | Mass (kg) | |
|---|---|---|---|---|---|---|---|---|
24.93 € | 1 | 6 Days | 129 | 102 | 763-0204 | 0.4 | ||
36.26 € | 1 | 6 Days | 156 | 127 | 763-0239 | 0.6 |
Loading...
Basic information
| Caster Type | Plate Type Fixed | Load Range(daN) | 80.01~140.00 | Stopper | NA |
|---|---|---|---|---|---|
| Allowable Load(daN) | 132 | Wheel Material | Nylon | Wheel Characteristics | Oil Resistance |
| Fitting Material | Stainless Steel | Mounting Hole Type | Round Hole | Mounting Hole Pitch Longitudinal direction(mm) | 76 |
| Mounting Hole Pitch Transverse Direction(mm) | 45 | Mounting Seat A×B(mm) | 95×64 | Wheel Width(mm) | 32 |
| Load Category | Medium Load | Mounting Hole Diameter P(mm) | 8 | The treatment of Metal fittings surface | Electrolytic Polishing |
| Ordering Unit(piece) | 1 |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
