The new M3/4GD1/2/3R-(D) series have inherited the legacy 3G/4G series concept and evolved it further.

[Environmental Performance]
· Continuous power OK (single solenoid type). Uses a new coil actuator.
· Reduced power consumption.
[Safety]
· Manual misoperation prevention (manual device has a protective cover).
· Suppresses malfunctioning problems (metal base, exhaust malfunction prevention valve regardless of resin block come as standard).
· Foreign matter problem prevention
[Reliability]
· Low sliding · Realizes long life
· Improved leave response
[Ease of use]
· Wiring connector horizontal sharing
· Uses rotary connector

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Part Number
4GD219R-06-[1,​2,​3,​4]
4GD219R-06-[B,​BN,​E00,​E01J,​E01,​E02J,​E02,​E03J,​E03,​E0N,​E0,​E1,​E2N,​E2,​E3,​E20,​E21J,​E21,​E22J,​E22,​E23J,​E23]-[1,​2,​3,​4]
4GD219R-C4-[1,​2,​3,​4]
4GD219R-C4-[B,​BN,​E00,​E01J,​E01,​E02J,​E02,​E03J,​E03,​E0N,​E0,​E1,​E2N,​E2,​E3,​E20,​E21J,​E21,​E22J,​E22,​E23J,​E23]-[1,​2,​3,​4]
4GD219R-C6-[1,​2,​3,​4]
4GD219R-C6-[B,​BN,​E00,​E01J,​E01,​E02J,​E02,​E03J,​E03,​E0N,​E0,​E1,​E2N,​E2,​E3,​E20,​E21J,​E21,​E22J,​E22,​E23J,​E23]-[1,​2,​3,​4]
4GD219R-C8-[1,​2,​3,​4]
4GD219R-C8-[B,​BN,​E00,​E01J,​E01,​E02J,​E02,​E03J,​E03,​E0N,​E0,​E1,​E2N,​E2,​E3,​E20,​E21J,​E21,​E22J,​E22,​E23J,​E23]-[1,​2,​3,​4]
Part NumberMinimum order quantityVolume Discount
Standard
Shipping Days
?
Voltage Pipe Port Type Nominal Pipe Thread Size Connection Tube Diameter Wire Connection Rc(R) Type Details
1 14 Days 12 V DC / 24 V DC / 100 V AC / 200 V ACRc--Grommet Lead Wire-
1 14 Days 12 V DC / 24 V DC / 100 V AC / 200 V ACRc--E00 / E0 / E0N / E1 / E01 / E01J / E2 / E02J / E2N / E03 / E3 / E03J / E20 / E21 / E21J / E22 / E22J / E23 / E23J / B / BN-
1 14 Days 12 V DC / 24 V DC / 100 V AC / 200 V ACSingle-Action Coupling--Grommet Lead Wire-
1 14 Days 12 V DC / 24 V DC / 100 V AC / 200 V ACSingle-Action Coupling--E00 / E0 / E0N / E1 / E01 / E01J / E2 / E02J / E2N / E03 / E3 / E03J / E20 / E21 / E21J / E22 / E22J / E23 / E23J / B / BN-
1 14 Days 12 V DC / 24 V DC / 100 V AC / 200 V ACSingle-Action Coupling--Grommet Lead Wire-
1 14 Days 12 V DC / 24 V DC / 100 V AC / 200 V ACSingle-Action Coupling--E00 / E0 / E0N / E1 / E01 / E01J / E2 / E02J / E2N / E03 / E3 / E03J / E20 / E21 / E21J / E22 / E22J / E23 / E23J / B / BN-
1 14 Days 12 V DC / 24 V DC / 100 V AC / 200 V ACSingle-Action Coupling--Grommet Lead Wire-
1 14 Days 12 V DC / 24 V DC / 100 V AC / 200 V ACSingle-Action Coupling--E00 / E0 / E0N / E1 / E01 / E01J / E2 / E02J / E2N / E03 / E3 / E03J / E20 / E21 / E21J / E22 / E22J / E23 / E23J / B / BN-

Loading...

  1. 1

Basic information

Type Electromagnetic Valve Application Unit for manifold Number of Ports 5-port valve
Installation method Manifold Base Features Standard / Oil-Free Number of Solenoids Single
Switching Type 2-position exhaust Status at Power Off Self-reset(differential pressure return) Compatible Cylinder Diameter(Ø) 40 to 80
Plumbing Direct piping Driving Type Pilot-operated Spool Seal Type Soft seal
