Drawn Cup Roller Clutch
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| FC-4K |
| FC-6 |
| FC-6K |
| FC-8 |
| FC-10 |
| FC-12 |
| FC-14K |
| FC-16 |
| FC-25 |
| FCB-8 |
| FCB-10 |
| FCB-12 |
| FCB-16 |
| FCB-20 |
| FCB-25 |
| FCB-30 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | Raceway Ring Shape | Internal Diameter (mm) | Outer Diameter (mm) | Width (mm) | Basic Load Rating, Dynamic Rating (N) | Low Torque Specification | |
|---|---|---|---|---|---|---|---|---|---|---|---|
5.54 € | 1 | Available | 5 Days | 10 | One-Way Clutch | 4 | 8 | 6 | - | Low Torque | |
5.31 € | 1 | 5 Days | 10 | One-Way Clutch | 6 | 10 | 12 | - | NA | ||
6.25 € | 1 | Available |
Same day
Stock | 10 | One-Way Clutch | 6 | 10 | 12 | - | Low Torque | |
6.25 € | 1 | Available |
Same day
Stock | 10 | One-Way Clutch | 8 | 14 | 12 | - | NA | |
5.55 € | 1 | 5 Days | 10 | One-Way Clutch | 10 | 16 | 12 | - | NA | ||
5.31 € | 1 | Available | 5 Days | 10 | One-Way Clutch | 12 | 18 | 16 | - | NA | |
5.68 € | 1 | 5 Days | 10 | One-Way Clutch | 14 | 20 | 16 | - | Low Torque | ||
6.86 € | 1 | Available |
Same day
Stock | 10 | One-Way Clutch | 16 | 22 | 16 | - | NA | |
8.86 € | 1 | Available |
Same day
Stock | 10 | One-Way Clutch | 25 | 32 | 20 | - | NA | |
11.64 € | 1 | 5 Days | 10 | Cylindrical Roller | 8 | 14 | 20 | 2430 | NA | ||
11.40 € | 1 |
Same day
Stock | 10 | Cylindrical Roller | 10 | 16 | 20 | 2820 | NA | ||
11.77 € | 1 |
Same day
Stock | 10 | Cylindrical Roller | 12 | 18 | 26 | 3800 | NA | ||
12.82 € | 1 | 5 Days | 10 | Cylindrical Roller | 16 | 22 | 26 | 4100 | NA | ||
13.60 € | 1 |
Same day
Stock | 10 | Cylindrical Roller | 20 | 26 | 26 | 5100 | NA | ||
15.35 € | 1 |
Same day
Stock | 10 | Cylindrical Roller | 25 | 32 | 30 | 6850 | NA | ||
17.96 € | 1 | 5 Days | 10 | Cylindrical Roller | 30 | 37 | 30 | 7000 | NA |
Loading...
Basic information
| Load Direction | Radial | Outer Ring | With Outer Ring | Inner/Outer Ring Material | Steel |
|---|---|---|---|---|---|
| Precision (JIS) | Grade 0 | Number of Raceway Ring Rows | Single Row | Size Standards | Metric System |
| Specifications | Standard | Rolling Element Material | Steel | Outer Ring Type | Flat |
| Retainer Type | Punching | Clearance sign | NA | Accuracy(Class) | NA |
| Bearing Ring Type | NA | Acoustic Symbol | NA | Holder Symbol | NA |
| Symbol of Bearing Ring Shape | NA | Seal, Shield Symbols | NA | Precision Grade Symbol | NA |
| Symbol of contact angle | NA | Special Configurations Code | NA | Symbols of Lubrication Amount | NA |
| Holder Color | NA | Internal Symbol | NA | Material Symbol | NA |
Configure
Stock
-
- Show only stock items
Basic Attributes
-
Raceway Ring Shape
- Cylindrical Roller
- One-Way Clutch
-
Internal Diameter(mm)
-
Outer Diameter(mm)
-
Width(mm)
-
Low Torque Specification
- Low Torque
- NA
-
Type
- FC
- FCB
-
Filter by CAD data type
- 2D
- 3D
Filter by standard shipping days
-
- All
- Same day
- 5 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
