Rectangular Multi-Connector (Inch Size) KDM Series
[Features]
· Requires less installation space than when using multiple bulkhead unions for panels.
· Multiple pipes can be attached and detached in a single action, meaning fewer piping mistakes with much less time needed to be spent on installation work.
· Being a one-touch fitting, it helps greatly reduce the amount of time spent on piping.
(i)Remark
- *See the catalog for detailed specs and materials.
- Product images may be representative images. Refer to the catalog for details.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| KDM10-01 |
| KDM10-03 |
| KDM10-07 |
| KDM10-09 |
| KDM20-03 |
| KDM20-07 |
| KDM20-09 |
| KDM20S-08-X12 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Fitting Type | Main Body Material | Union: Same Diameter | Other Shapes | Number of Connection Tubes (pc.) | Release button color | Custom-made specifications | |
|---|---|---|---|---|---|---|---|---|---|---|---|
91.39 € | 1 | 26 Days | Union with same diameter | [PP Resin] PP | [Manifold] Multi-Connector | - | 10 | Red | N/A | ||
89.40 € | 1 | 26 Days | Union with same diameter | [PP Resin] PP | [Manifold] Multi-Connector | - | 10 | Red | N/A | ||
91.39 € | 1 | 26 Days | Union with same diameter | [PP Resin] PP | [Manifold] Multi-Connector | - | 10 | Red | N/A | ||
129.11 € | 1 | 26 Days | Union with same diameter | [Brass] EN CW614N Equiv.+PBT | [Manifold] Multi-Connector | - | 10 | Red | N/A | ||
164.85 € | 1 | 26 Days | Union with same diameter | [PP Resin] PP | [Manifold] Multi-Connector | - | 20 | Red | N/A | ||
168.77 € | 1 | 26 Days | Union with same diameter | [PP Resin] PP | [Manifold] Multi-Connector | - | 20 | Red | N/A | ||
244.24 € | 1 | 26 Days | Union with same diameter | [Brass] EN CW614N Equiv.+PBT | [Manifold] Multi-Connector | - | 20 | Red | N/A | ||
122.06 € | 1 | Quote | Other Shapes | [PP Resin] PP | - | [Unequal Dia. Sockets] Socket connector | - | - | - |
Loading...
Basic information
| Type | Single-Action | Applicable Fluid | Air | Application | Standard/Mini |
|---|---|---|---|---|---|
| Packing, Material of O-Ring | EPDM (Fluorine Coating) |
