General-Purpose/Standard Pressure Gauge | 0.2 | 42.5 | Back side thread | 0.2 MPa | R 1/8 | None | 42.5 | None | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.2 | 57 | Back side thread | 0.2 MPa | R 1/8 | None | 57 | None | Clear cover has no protrusion (clear cover cannot be removed) | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.2 | 57 | Back side thread | 0.2 MPa | R 1/8 | None | 57 | None | Clear cover has protrusion. (Clear cover is removable). The wrench flats protrude. | 1 pieces |
- | - | - | Back side thread | 0.2 MPa | R 1/8 | With M5 (female thread) | 42.5 | None | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.2 | 57 | Back side thread | 0.2 MPa | R 1/8 | With M5 (female thread) | 57 | None | Clear cover has no protrusion (clear cover cannot be removed) | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.2 | 42.5 | Back side thread | 0.2 MPa | R 1/4 | None | 42.5 | None | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.2 | 57 | Back side thread | 0.2 MPa | R 1/4 | None | 57 | None | Clear cover has no protrusion (clear cover cannot be removed) | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.2 | 42.5 | Back side thread | 0.2 MPa | R 1/4 | With M5 (female thread) | 42.5 | None | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.2 | 57 | Back side thread | 0.2 MPa | R 1/4 | With M5 (female thread) | 57 | None | Clear cover has no protrusion (clear cover cannot be removed) | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.4 | 42.5 | Back side thread | 0.4 MPa | R 1/8 | None | 42.5 | None | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.4 | 57 | Back side thread | 0.4 MPa | R 1/8 | None | 57 | None | Clear cover has no protrusion (clear cover cannot be removed) | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.4 | 57 | Back side thread | 0.4 MPa | R 1/8 | None | 57 | None | Clear cover has protrusion. (Clear cover is removable). The wrench flats protrude. | 1 pieces |
- | - | - | Back side thread | 0.4 MPa | R 1/8 | With M5 (female thread) | 42.5 | None | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.4 | 57 | Back side thread | 0.4 MPa | R 1/8 | With M5 (female thread) | 57 | None | Clear cover has no protrusion (clear cover cannot be removed) | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.4 | 42.5 | Back side thread | 0.4 MPa | R 1/4 | None | 42.5 | None | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.4 | 57 | Back side thread | 0.4 MPa | R 1/4 | None | 57 | None | Clear cover has no protrusion (clear cover cannot be removed) | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.4 | 42.5 | Back side thread | 0.4 MPa | R 1/4 | With M5 (female thread) | 42.5 | None | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.4 | 57 | Back side thread | 0.4 MPa | R 1/4 | With M5 (female thread) | 57 | None | Clear cover has no protrusion (clear cover cannot be removed) | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.7 | 42.5 | Back side thread | 0.7 MPa | R 1/8 | None | 42.5 | None | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.7 | 57 | Back side thread | 0.7 MPa | R 1/8 | None | 57 | None | Clear cover has no protrusion (clear cover cannot be removed) | 1 pieces |
- | - | - | Back side thread | 0.7 MPa | R 1/8 | None | 57 | None | Clear cover has a protrusion (clear cover can be removed) | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.7 | 42.5 | Back side thread | 0.7 MPa | R 1/8 | With M5 (female thread) | 42.5 | None | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.7 | 57 | Back side thread | 0.7 MPa | R 1/8 | With M5 (female thread) | 57 | None | Clear cover has no protrusion (clear cover cannot be removed) | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.7 | 42.5 | Back side thread | 0.7 MPa | R 1/4 | None | 42.5 | None | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.7 | 57 | Back side thread | 0.7 MPa | R 1/4 | None | 57 | None | Clear cover has no protrusion (clear cover cannot be removed) | 1 pieces |
- | - | - | Back side thread | 0.7 MPa | R 1/4 | None | 57 | Oil-free (wetted parts degrease washing) | Clear cover has no protrusion (clear cover cannot be removed) | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.7 | 42.5 | Back side thread | 0.7 MPa | R 1/4 | With M5 (female thread) | 42.5 | None | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.7 | 57 | Back side thread | 0.7 MPa | R 1/4 | With M5 (female thread) | 57 | None | Clear cover has no protrusion (clear cover cannot be removed) | 1 pieces |
General-Purpose/Standard Pressure Gauge | 1 | 42.5 | Back side thread | 1.0 MPa | R 1/8 | None | 42.5 | None | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 1 | 57 | Back side thread | 1.0 MPa | R 1/8 | None | 57 | None | Clear cover has no protrusion (clear cover cannot be removed) | 1 pieces |
General-Purpose/Standard Pressure Gauge | 1 | 57 | Back side thread | 1.0 MPa | R 1/8 | None | 57 | None | Clear cover has protrusion. (Clear cover is removable). The wrench flats protrude. | 1 pieces |
General-Purpose/Standard Pressure Gauge | 1 | 42.5 | Back side thread | 1.0 MPa | R 1/8 | With M5 (female thread) | 42.5 | None | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 1 | 57 | Back side thread | 1.0 MPa | R 1/8 | With M5 (female thread) | 57 | None | Clear cover has no protrusion (clear cover cannot be removed) | 1 pieces |
General-Purpose/Standard Pressure Gauge | 1 | 57 | Back side thread | 1.0 MPa | R 1/8 | With M5 (female thread) | 57 | None | Clear cover has protrusion. (Clear cover is removable). The wrench flats protrude. | 1 pieces |
General-Purpose/Standard Pressure Gauge | 1 | 42.5 | Back side thread | 1.0 MPa | R 1/4 | None | 42.5 | None | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 1 | 57 | Back side thread | 1.0 MPa | R 1/4 | None | 57 | None | Clear cover has no protrusion (clear cover cannot be removed) | 1 pieces |
General-Purpose/Standard Pressure Gauge | 1 | 57 | Back side thread | 1.0 MPa | R 1/4 | None | 57 | None | Clear cover has protrusion. (Clear cover is removable). The wrench flats protrude. | 1 pieces |
General-Purpose/Standard Pressure Gauge | 1 | 42.5 | Back side thread | 1.0 MPa | R 1/4 | With M5 (female thread) | 42.5 | None | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 1 | 57 | Back side thread | 1.0 MPa | R 1/4 | With M5 (female thread) | 57 | None | Clear cover has no protrusion (clear cover cannot be removed) | 1 pieces |
General-Purpose/Standard Pressure Gauge | 1.5 | 42.5 | Back side thread | 1.5 MPa | R 1/8 | None | 42.5 | None | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 1.5 | 57 | Back side thread | 1.5 MPa | R 1/8 | None | 57 | None | Clear cover has no protrusion (clear cover cannot be removed) | 1 pieces |
- | - | - | Back side thread | 1.5 MPa | R 1/8 | With M5 (female thread) | 42.5 | None | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 1.5 | 42.5 | Back side thread | 1.5 MPa | R 1/4 | None | 42.5 | None | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 1.5 | 57 | Back side thread | 1.5 MPa | R 1/4 | None | 57 | None | Clear cover has no protrusion (clear cover cannot be removed) | 1 pieces |
- | - | - | Back side thread | 1.5 MPa | R 1/4 | With M5 (female thread) | 42.5 | None | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.2 | 42.5 | Vertical side thread | 0.2 MPa | R 1/8 | None | 42.5 | None | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.2 | 42.5 | Vertical side thread | 0.2 MPa | R 1/4 | None | 42.5 | None | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.4 | 42.5 | Vertical side thread | 0.4 MPa | R 1/8 | None | 42.5 | None | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.4 | 42.5 | Vertical side thread | 0.4 MPa | R 1/4 | None | 42.5 | None | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.7 | 42.5 | Vertical side thread | 0.7 MPa | R 1/8 | None | 42.5 | None | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 0.7 | 42.5 | Vertical side thread | 0.7 MPa | R 1/4 | None | 42.5 | None | Without cover ring assembly | 1 pieces |
- | - | - | Vertical side thread | 0.7 MPa | R 1/4 | None | 42.5 | Nickel plating | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 1 | 42.5 | Vertical side thread | 1.0 MPa | R 1/8 | None | 42.5 | None | Without cover ring assembly | 1 pieces |
- | - | - | Vertical side thread | 1.0 MPa | R 1/8 | None | 42.5 | Nickel plating | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 1 | 42.5 | Vertical side thread | 1.0 MPa | R 1/4 | None | 42.5 | None | Without cover ring assembly | 1 pieces |
- | - | - | Vertical side thread | 1.0 MPa | R 1/4 | None | 42.5 | Nickel plating | Without cover ring assembly | 1 pieces |
- | - | - | Vertical side thread | 1.5 MPa | R 1/8 | None | 42.5 | None | Without cover ring assembly | 1 pieces |
- | - | - | Vertical side thread | 1.5 MPa | R 1/8 | None | 42.5 | Nickel plating | Without cover ring assembly | 1 pieces |
General-Purpose/Standard Pressure Gauge | 1.5 | 42.5 | Vertical side thread | 1.5 MPa | R 1/4 | None | 42.5 | None | Without cover ring assembly | 1 pieces |
- | - | - | Vertical side thread | 1.5 MPa | R 1/4 | None | 42.5 | Nickel plating | Without cover ring assembly | 1 pieces |
