MHC2, Air Gripper, Angular Style
- Promotional pricing ends 31/12/2024
[Features]
· A compact design in which a large amount of gripping force is provided through the use of a double piston mechanism.
· Built-in variable throttle.
· A solid state auto switch with an indicator light can be mounted.
(i)Remark
- The products shown in the image are representative. CAD data is not supported for some model numbers.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Operation Method | Claw Opening Angle A1 (deg) | Claw Closing Angle A2 (deg) | Cylinder internal diameter (mm) | Auto switch | Number of switches | Lead wire length | Made to order specifications | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
197.90 € 130.61 € | 1 |
Same day
Stock | Double Acting | 30 | 10 | 10 | None | None | None | None | ||
265.52 € | 1 | 26 Days | Double Acting | 30 | 10 | 10 | M9BW | 2 pcs. | 0.5 m | None | ||
273.03 € | 1 | 26 Days | Double Acting | 30 | 10 | 10 | M9BW | 2 pcs. | 3 m | None | ||
273.03 € | 1 | 26 Days | Double Acting | 30 | 10 | 10 | M9BWV | 2 pcs. | 0.5 m | None | ||
280.58 € | 1 | 26 Days | Double Acting | 30 | 10 | 10 | M9BWV | 2 pcs. | 3 m | None | ||
288.82 € | 1 | 26 Days | Double Acting | 30 | 10 | 10 | M9NW | 2 pcs. | 0.5 m | None | ||
278.21 € | 1 | 26 Days | Double Acting | - | - | - | - | - | - | - | ||
232.61 € | 1 | 98 Days | Double Acting | 30 | 10 | 10 | None | None | None | Fluoroelastomer seal | ||
295.24 € | 1 | 26 Days | Double Acting | 30 | 10 | 10 | None | None | None | Axial ported | ||
197.90 € | 1 | 4 Days | Single Acting Type (Normally Open) | 30 | 10 | 10 | None | None | None | None | ||
231.11 € | 1 | 26 Days | Single Acting Type (Normally Open) | 30 | 10 | 10 | None | None | None | Heat resistance (100°C) | ||
260.24 € | 1 | 26 Days | Single Acting Type (Normally Open) | 30 | 10 | 10 | None | None | None | Axial ported | ||
214.13 € | 1 | 3 Days | Double Acting | 30 | 10 | 16 | None | None | None | None | ||
283.56 € | 1 | 26 Days | Double Acting | 30 | 10 | 16 | M9B | 2 pcs. | 3 m | None | ||
289.31 € | 1 | 26 Days | Double Acting | 30 | 10 | 16 | M9BW | 2 pcs. | 3 m | None | ||
289.29 € | 1 | 26 Days | Double Acting | 30 | 10 | 16 | M9BWV | 2 pcs. | 0.5 m | None | ||
294.45 € | 1 | 26 Days | Double Acting | - | - | - | - | - | - | - | ||
251.60 € | 1 | 98 Days | Double Acting | 30 | 10 | 16 | None | None | None | Heat resistance (100°C) | ||
214.13 € | 1 | 4 Days | Single Acting Type (Normally Open) | 30 | 10 | 16 | None | None | None | None | ||
294.45 € | 1 | 26 Days | Single Acting Type (Normally Open) | - | - | - | - | - | - | - | ||
246.24 € | 1 | 26 Days | Single Acting Type (Normally Open) | 30 | 10 | 16 | None | None | None | Fluoroelastomer seal | ||
291.02 € | 1 | 26 Days | Single Acting Type (Normally Open) | 30 | 10 | 16 | None | None | None | Axial ported | ||
227.60 € | 1 | 26 Days | Single Acting Type (Normally Open) | 30 | 10 | 16 | None | None | None | Grease for food processing machines / fluorine grease | ||
246.65 € | 1 | 3 Days | Double Acting | 30 | 10 | 20 | None | None | None | None | ||
281.35 € | 1 | 26 Days | Double Acting | 30 | 10 | 20 | M9B | 1 pc. | 3 m | None | ||
314.27 € | 1 | 26 Days | Double Acting | 30 | 10 | 20 | M9BW | 2 pcs. | 0.5 m | None | ||
321.81 € | 1 | 26 Days | Double Acting | 30 | 10 | 20 | M9BW | 2 pcs. | 3 m | None | ||
280.45 € | 1 | 26 Days | Double Acting | 30 | 10 | 20 | M9BW | 1 pc. | 0.5 m | None | ||
321.81 € | 1 | 26 Days | Double Acting | 30 | 10 | 20 | M9BWV | 2 pcs. | 0.5 m | None | ||
329.32 € | 1 | 26 Days | Double Acting | 30 | 10 | 20 | M9BWV | 2 pcs. | 3 m | None | ||
317.98 € | 1 | 26 Days | Double Acting | 30 | 10 | 20 | M9N | 2 pcs. | 3 m | None | ||
326.97 € | 1 | 26 Days | Double Acting | - | - | - | - | - | - | - | ||
343.82 € | 1 | 26 Days | Double Acting | 30 | 10 | 20 | None | None | None | Axial ported | ||
246.65 € | 1 | 4 Days | Single Acting Type (Normally Open) | 30 | 10 | 20 | None | None | None | None | ||
280.45 € | 1 | 26 Days | Single Acting Type (Normally Open) | 30 | 10 | 20 | M9BW | 1 pc. | 0.5 m | None | ||
284.63 € 187.86 € | 1 |
Same day
Stock | Double Acting | 30 | 10 | 25 | None | None | None | None | ||
352.26 € | 1 | 26 Days | Double Acting | 30 | 10 | 25 | M9BW | 2 pcs. | 0.5 m | None | ||
318.44 € | 1 | 26 Days | Double Acting | 30 | 10 | 25 | M9BW | 1 pc. | 0.5 m | None | ||
359.77 € | 1 | 26 Days | Double Acting | 30 | 10 | 25 | M9BWV | 2 pcs. | 0.5 m | None | ||
361.60 € | 1 | 26 Days | Double Acting | 30 | 10 | 25 | M9B | 2 pcs. | 5 m | None | ||
355.97 € | 1 | 26 Days | Double Acting | 30 | 10 | 25 | M9N | 2 pcs. | 3 m | None | ||
352.26 € | 1 | 26 Days | Double Acting | 30 | 10 | 25 | M9NW | 2 pcs. | 0.5 m | None | ||
370.34 € | 1 | 26 Days | Double Acting | - | - | - | - | - | - | - | ||
327.82 € | 1 | 26 Days | Double Acting | 30 | 10 | 25 | M9PV | 1 pc. | 5 m | None | ||
418.76 € | 1 | 26 Days | Double Acting | 30 | 10 | 25 | None | None | None | Axial ported | ||
321.03 € | 1 | 26 Days | Double Acting | 30 | 10 | 25 | None | None | None | Grease for food processing machines / fluorine grease | ||
284.63 € | 1 | 4 Days | Single Acting Type (Normally Open) | 30 | 10 | 25 | None | None | None | None | ||
345.97 € | 1 | 26 Days | Single Acting Type (Normally Open) | 30 | 10 | 25 | None | None | None | Axial ported |
Loading...
Basic information
| Type | Main Body | How to Grip | Pinch, Swing Type / Open, Swing Type | Number of Fingers | 2 pcs. |
|---|---|---|---|---|---|
| Main Body Shape | Square Shape | Environment, Applications | Standard | Additional Function | Not Provided |
| Stroke Adjustment Mechanism | Not Provided |
Configure
Stock
-
- Show only stock items
Basic Attributes
-
Operation Method
- Double Acting
- Single Acting Type (Normally Open)
-
Cylinder internal diameter(mm)
-
Auto switch
-
Number of switches
-
Lead wire length
- 0.5 m
- 3 m
- 5 m
- None
-
Made to order specifications
- Heat resistance (100°C)
- Axial ported
- Fluoroelastomer seal
- Grease for food processing machines / fluorine grease
- None
-
Type
- MHC2-10
- MHC2-16
- MHC2-20
- MHC2-25
-
Filter by CAD data type
- 2D
- 3D
Filter by standard shipping days
-
- All
- Same day
- 3 Days or Less
- 4 Days or Less
- 26 Days or Less
- 98 Days or Less
Optional Attributes
- The products shown in the image are representative. CAD data is not supported for some model numbers.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
