[In-stock item] Explosion-Proof Pilot Type 2 Port Solenoid Valve ADK11E4 Series
![[In-stock item] Explosion-Proof Pilot Type 2 Port Solenoid Valve ADK11E4 Series](http://uk.misumi-ec.com/linked/material/mech/CKD1/PHOTO/221006398854_001.jpg?$product_main$)
Same day shipping before 18:00 is available for the model numbers mentioned on this page.
[Features]
"Valuing Life and Sustaining Business Activity" is our motto. To serve your automation and energy conservation needs in hazardous locations,
we developed an explosion-proof valve based on the reliability and quality of the Multilex valve.
[Safety precautions]
The ethylene propylene rubber (EPDM) seal combination cannot be used with air as the fluid.
(This is because compressed air contains oil, and EPDM is not oil-resistant.)
[Features]
"Valuing Life and Sustaining Business Activity" is our motto. To serve your automation and energy conservation needs in hazardous locations,
we developed an explosion-proof valve based on the reliability and quality of the Multilex valve.
[Safety precautions]
The ethylene propylene rubber (EPDM) seal combination cannot be used with air as the fluid.
(This is because compressed air contains oil, and EPDM is not oil-resistant.)
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| ADK11E4-15A-03T-AC100V |
| ADK11E4-15A-03T-AC200V |
| ADK11E4-20A-03T-AC100V |
| ADK11E4-20A-03T-AC200V |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Nominal Pipe Thread Size | Orifice Diameter (mm) | Voltage | |
|---|---|---|---|---|---|---|---|
326.65 € | 1 | 8 Days | 1/2 | 16 | 100 V AC | ||
326.65 € | 1 | 6 Days | 1/2 | 16 | 200 V AC | ||
337.77 € | 1 | 6 Days | 3/4 | 23 | 100 V AC | ||
337.77 € | 1 | 6 Days | 3/4 | 23 | 200 V AC |
Loading...
Basic information
| Type | Electromagnetic | Applicable Fluid | Air / Water / Vacuum / Oil | Operating Environment | Standard / Explosion Proofing |
|---|---|---|---|---|---|
| Switching Type | 2-Port Normally Open | Connection Type | Rc | Driving Type | Pilot kick Type |
| Operating Temperature Range(℃) | -10::60 | Number of Solenoids | Single | Application | Single Item |
| Body Material | Bronze | Sealing Material | NBR | Coil Symbol | 3T |
| Coil Option | External lead wire method, intake method: conduit-thread connection (G1/2) |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
