Adjustable flat tension levers with tabbed stud, Stainless Steel

Adjustable flat tension levers with tabbed stud, Stainless Steel

Part number:

Still undefined. 16 possible part numbers found.
Quantity:

Part number list

Number of items
  • 1
    • Part number
    125.5-32-M6-D
    Order suspended
    125.5-32-M6-E
    Order suspended
    125.5-32-M8-D
    Order suspended
    125.5-32-M8-E
    Order suspended
    125.5-36-M8-D
    Order suspended
    125.5-36-M8-E
    125.5-36-M10-D
    Order suspended
    125.5-36-M10-E
    Order suspended
    125.5-40-M10-D
    Order suspended
    125.5-40-M10-E
    125.5-40-M12-D
    125.5-40-M12-E
    Order suspended
    125.5-45-M12-D
    Order suspended
    125.5-45-M12-E
    125.5-45-M16-D
    Order suspended
    125.5-45-M16-E

    Diameter d1

    Connection thread d2

    Type

    		Minimum order quantity
    32
    M 6
    D, straight lever
    1 pieces
    32
    M 6
    E, angled lever
    1 pieces
    32
    M 8
    D, straight lever
    1 pieces
    32
    M 8
    E, angled lever
    1 pieces
    36
    M 8
    D, straight lever
    1 pieces
    36
    M 8
    E, angled lever
    1 pieces
    36
    M 10
    D, straight lever
    1 pieces
    36
    M 10
    E, angled lever
    1 pieces
    40
    M 10
    D, straight lever
    1 pieces
    40
    M 10
    E, angled lever
    1 pieces
    40
    M 12
    D, straight lever
    1 pieces
    40
    M 12
    E, angled lever
    1 pieces
    45
    M 12
    D, straight lever
    1 pieces
    45
    M 12
    E, angled lever
    1 pieces
    45
    M 16
    D, straight lever
    1 pieces
    45
    M 16
    E, angled lever
    1 pieces
    Unit price (excluding VAT)(Unit price including VAT)
    Standard shipping days
    35.52 €
    ( 42.27 € )
    7 working days
    37.22 €
    ( 44.29 € )
    7 working days
    35.52 €
    ( 42.27 € )
    7 working days
    37.22 €
    ( 44.29 € )
    7 working days
    40.74 €
    ( 48.48 € )
    7 working days
    42.44 €
    ( 50.50 € )
    7 working days
    40.74 €
    ( 48.48 € )
    7 working days
    42.44 €
    ( 50.50 € )
    7 working days
    48.00 €
    ( 57.12 € )
    7 working days
    49.70 €
    ( 59.14 € )
    7 working days
    48.00 €
    ( 57.12 € )
    7 working days
    49.70 €
    ( 59.14 € )
    7 working days
    57.92 €
    ( 68.92 € )
    7 working days
    59.62 €
    ( 70.95 € )
    7 working days
    57.92 €
    ( 68.92 € )
    7 working days
    59.62 €
    ( 70.95 € )
    7 working days
  • 1

    • More Information

    Basic information

    The overall height of Stainless Steel-Flat tension levers GN 125.5 is reduced to a minimum.
    As all other adjustable levers, they are ideal whenever parts have to be clamped in a confined space, or a particular lever position is required. The threaded insert is connected with the hub via serrations which can be disengaged.
    Pulling the lever, disengages the serrations and the lever can be swivelled to the ideal clamping position. On releasing the lever it will automatically re-engage.
