SFD, Clean Air Filter
[Features]
· Filtration: 0.01 μm.
· Initial pressure drop: 0.03 MPa.
· Maximum operating pressure: 1.0 MPa.
[Applications]
· Use with clean air blowers / ionizer blowers.
· Use for chamber substitution and fluid pumping.
(i)Remark
- The products shown in the image are representative. CAD data is not supported for some model numbers.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Type | Connection Type | Nominal Pipe Thread Size | Bowl Material | Connection Tube Diameter | Size of Body | Accessory | Connection type on OUT side | Connection port diameter on OUT side | Connection tube diameter on OUT side | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
105.60 € | 1 | 26 Days | Standard | [One-Touch Plumbing] Single-Action Pipe | 1/4 | [Resin] Nylon case with case guard | - | 1 | None | Rc | 1/4 | - | ||
108.24 € | 1 | 4 Days | Standard | [One-Touch Plumbing] Single-Action Pipe | 1/4 | [Resin] Nylon case with case guard | - | 1 | Bracket | Rc | 1/4 | - | ||
121.58 € | 1 |
Same day
Stock | Standard | [One-Touch Plumbing] One-Touch Pipe (Elbow) | - | [Resin] Nylon case with case guard | φ4 | 1 | None | One-touch piping | - | ø4 | ||
124.23 € | 1 | 39 Days | Standard | [One-Touch Plumbing] One-Touch Pipe (Elbow) | - | [Resin] Nylon case with case guard | φ4 | 1 | Bracket | One-touch piping | - | ø4 | ||
127.95 € | 1 | 26 Days | Standard | [One-Touch Plumbing] One-Touch Pipe (Elbow) | - | [Resin] Nylon case with case guard | φ4 | 1 | None | One-touch piping | - | ø6 | ||
121.58 € | 1 | 4 Days | Standard | [One-Touch Plumbing] One-Touch Pipe (Elbow) | - | [Resin] Nylon case with case guard | φ6 | 1 | None | One-touch piping | - | ø6 | ||
124.23 € | 1 | 4 Days | Standard | [One-Touch Plumbing] One-Touch Pipe (Elbow) | - | [Resin] Nylon case with case guard | φ6 | 1 | Bracket | One-touch piping | - | ø6 | ||
127.95 € | 1 | 26 Days | Standard | [One-Touch Plumbing] One-Touch Pipe (Elbow) | - | [Resin] Nylon case with case guard | φ6 | 1 | None | One-touch piping | - | ø4 | ||
130.73 € | 1 | 26 Days | [Standard] Standard | [One-Touch Plumbing] One-Touch Pipe (Elbow) | - | [Resin] Nylon case with case guard | φ6 | 1 | Bracket | One-touch piping | - | ø8 | ||
121.58 € | 1 | 41 Days | Standard | [One-Touch Plumbing] One-Touch Pipe (Elbow) | - | [Resin] Nylon case with case guard | φ8 | 1 | None | One-touch piping | - | ø8 | ||
124.23 € | 1 | 26 Days | Standard | [One-Touch Plumbing] One-Touch Pipe (Elbow) | - | [Resin] Nylon case with case guard | φ8 | 1 | Bracket | One-touch piping | - | ø8 | ||
130.73 € | 1 | 26 Days | Standard | [One-Touch Plumbing] One-Touch Pipe (Elbow) | - | [Resin] Nylon case with case guard | φ8 | 1 | Bracket | One-touch piping | - | ø6 | ||
105.60 € | 1 | 4 Days | Standard | [G] G | 1/4 | [Resin] Nylon case with case guard | - | 1 | None | G | 1/4 | - | ||
108.24 € | 1 | 26 Days | Standard | [G] G | 1/4 | [Resin] Nylon case with case guard | - | 1 | Bracket | G | 1/4 | - | ||
105.60 € | 1 | 26 Days | Standard | [NPT] NPT | 1/4 | [Resin] Nylon case with case guard | - | 1 | None | NPT | 1/4 | - | ||
108.19 € | 1 | 26 Days | Standard | [NPT] NPT | 1/4 | [Resin] Nylon case with case guard | - | 1 | Bracket | NPT | 1/4 | - | ||
176.37 € | 1 | 26 Days | Standard | [One-Touch Plumbing] Single-Action Pipe | 1/4 | [Metal] Aluminum | - | 1 | None | Rc | 1/4 | - | ||
176.37 € | 1 | 26 Days | Standard | [G] G | 1/4 | [Metal] Aluminum | - | 1 | None | G | 1/4 | - | ||
176.37 € | 1 | 26 Days | Standard | [NPT] NPT | 1/4 | [Metal] Aluminum | - | 1 | None | NPT | 1/4 | - | ||
382.15 € | 1 | 26 Days | Standard | [One-Touch Plumbing] Single-Action Pipe | 1/4 | [Metal] Stainless Steel | - | 1 | None | Rc | 1/4 | - | ||
434.23 € | 1 | 26 Days | Standard | [G] G | 1/4 | [Metal] Stainless Steel | - | 1 | None | G | 1/4 | - | ||
382.15 € | 1 | 26 Days | Standard | [NPT] NPT | 1/4 | [Metal] Stainless Steel | - | 1 | None | NPT | 1/4 | - | ||
232.48 € | 1 | 26 Days | Standard | [One-Touch Plumbing] Single-Action Pipe | 1/4 | [Resin] Nylon case with case guard | - | 2 | None | Rc | 1/4 | - | ||
232.48 € | 1 | 4 Days | Standard | [One-Touch Plumbing] One-Touch Pipe (Elbow) | - | [Resin] Nylon case with case guard | φ8 | 2 | None | One-touch piping | - | ø8 | ||
244.56 € | 1 | 26 Days | Standard | [One-Touch Plumbing] One-Touch Pipe (Elbow) | - | [Resin] Nylon case with case guard | φ8 | 2 | None | One-touch piping | - | ø10 | ||
232.48 € | 1 | 4 Days | Standard | [One-Touch Plumbing] One-Touch Pipe (Elbow) | - | [Resin] Nylon case with case guard | φ10 | 2 | None | One-touch piping | - | ø10 | ||
244.56 € | 1 | 26 Days | Standard | [One-Touch Plumbing] One-Touch Pipe (Elbow) | - | [Resin] Nylon case with case guard | φ10 | 2 | None | One-touch piping | - | ø8 | ||
232.48 € | 1 | 4 Days | Standard | [One-Touch Plumbing] One-Touch Pipe (Elbow) | - | [Resin] Nylon case with case guard | φ12 | 2 | None | One-touch piping | - | ø12 | ||
232.48 € | 1 | 4 Days | Standard | [G] G | 1/4 | [Resin] Nylon case with case guard | - | 2 | None | G | 1/4 | - |
Loading...
Basic information
| Compressed Air Quality | General Dry Air | Filtration Level | 0.01μm | Usage Environment | Standard / Clean Room Specifications (Prevent dust) |
|---|---|---|---|---|---|
| Drain Cock | NA | Bowl Guard | NA |
