Axial cylindrical roller bearings 894, single direction, comprising K894, GS, WS
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 89412-TV |
| 89413-TV |
| 89414-TV |
| 89416-M |
| 89417-M |
| 89418-M |
| 89420-M |
| 89422-M |
| 89424-M |
| 89434-M |
| 89448-M |
| 89452-M |
| 89460-M |
| 89464-M |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Internal Diameter (mm) | Outer Diameter (mm) | Width (mm) | Allowable Rotational Speed (1/min) | Basic Load Rating, Dynamic Rating (Ca) (N) | Basic Load Rating, Static Rating (Coa) (N) | RoHS Certificate | REACH Certificate | Customs tariff — weight | Customs tariff — weight unit | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
607.43 € | 1 | 17 Days | 60 | 130 | 42 | 3050 | 390000 | 1220000 | - | - | - | - | |||
698.52 € | 1 | 17 Days | 65 | 140 | 45 | 2800 | 445000 | 1410000 | - | - | - | - | |||
802.43 € | 1 | 17 Days | 70 | 150 | 48 | 2600 | 475000 | 1500000 | - | - | - | - | |||
| - | 842.98 € | 1 | Available | 3 Days | 80 | 170 | 54 | - | - | - | - | - | - | - | |
| - | 1,961.62 € | 1 | 17 Days | 85 | 180 | 58 | - | - | - | - | - | - | - | ||
| - | 2,147.65 € | 1 | Available | 5 Days | 90 | 190 | 60 | - | - | - | - | - | - | - | |
| - | 2,101.97 € | 1 | 17 Days | 100 | 210 | 67 | - | - | - | - | - | - | - | ||
| - | 1,844.14 € | 1 | Available | 3 Days | 110 | 230 | 73 | - | - | - | - | - | - | - | |
| - | 2,166.27 € | 1 | 17 Days | 120 | 250 | 78 | - | - | - | - | - | - | - | ||
| - | 5,959.68 € | 1 | Available | 5 Days | 170 | 340 | 103 | - | - | - | - | - | - | - | |
| - | 11,617.49 € | 1 | Available | 3 Days | 240 | 440 | 122 | - | - | - | Available | Available | 95.9 | kg | |
| - | 14,572.10 € | 1 | Available | 4 Days | 260 | 480 | 132 | - | - | - | Available | Available | 114 | kg | |
| - | 20,383.12 € | 1 | Available | 4 Days | 300 | 540 | 145 | - | - | - | Available | Available | 163.87 | kg | |
| - | 24,577.83 € | 1 | Available | 4 Days | 320 | 580 | 155 | - | - | - | Available | Available | 207.28 | kg |
Loading...
Configure
Basic Attributes
-
Internal Diameter(mm)
-
Outer Diameter(mm)
-
Width(mm)
-
RoHS Certificate
- Available
-
REACH Certificate
- Available
-
Customs tariff — weight
-
Customs tariff — weight unit
- kg
-
Type
- 894
-
Filter by CAD data type
- 3D
Filter by standard shipping days
-
- All
- 3 Days or Less
- 4 Days or Less
- 5 Days or Less
- 17 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
