Axial deep groove ball bearings / single direction / 523 / similar to DIN 711, ISO 104 / FAG
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 52305 |
| 52306 |
| 52307 |
| 52308 |
| 52309 |
| 52310 |
| 52311 |
| 52312 |
| 52313 |
| 52314 |
| 52315 |
| 52316 |
| 52317 |
| 52318 |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Inner Diameter d (φ) | Outer Diameter D (φ) | Width B (or T) (mm) | Maximum Allowable Rotational Speed (1/min) | Basic Load Rating Dynamic Rating (Ca) (N) | Basic Load Rating Static Rating(Coa) (N) | RoHS Certificate | REACH Certificate | Customs tariff — weight | Customs tariff — weight unit | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
70.85 € | 1 | Available | 5 Days | 20 | 52 | 34 | 6000 | 34500 | 55000 | - | - | - | - | ||
72.18 € | 1 | Available | 5 Days | 25 | 60 | 38 | 5700 | 35500 | 65000 | - | - | - | - | ||
77.88 € | 1 | Available | 5 Days | 30 | 68 | 44 | 4850 | 50000 | 89000 | - | - | - | - | ||
82.26 € | 1 | Available | 3 Days | 30 | 78 | 49 | 4250 | 61000 | 112000 | - | - | - | - | ||
116.60 € | 1 | Available | 5 Days | 35 | 85 | 52 | 3800 | 75000 | 140000 | - | - | - | - | ||
145.48 € | 1 | Available | 3 Days | 40 | 95 | 58 | 3550 | 82000 | 169000 | - | - | - | - | ||
224.50 € | 1 | Available | 5 Days | 45 | 105 | 64 | 3200 | 102000 | 207000 | - | - | - | - | ||
206.29 € | 1 | Available | 3 Days | 50 | 110 | 64 | 3150 | 101000 | 207000 | - | - | - | - | ||
433.56 € | 1 | 17 Days | 55 | 115 | 65 | 3050 | 105000 | 220000 | - | - | - | - | |||
367.08 € | 1 | Available | 3 Days | 55 | 125 | 72 | 2750 | 134000 | 290000 | - | - | - | - | ||
427.21 € | 1 | Available | 5 Days | 60 | 135 | 79 | 2480 | 163000 | 360000 | - | - | - | - | ||
450.95 € | 1 | 17 Days | 65 | 140 | 79 | 2460 | 160000 | 360000 | - | - | - | - | |||
513.82 € | 1 | Available | 3 Days | 70 | 150 | 87 | 2260 | 186000 | 420000 | Available | Available | 6.43 | kg | ||
635.46 € | 1 | Available | 3 Days | 75 | 155 | 88 | 2240 | 193000 | 455000 | Available | Available | 6.6 | kg |
Loading...
Basic information
| Load Direction | Thrust |
|---|
Configure
Basic Attributes
-
Inner Diameter d(φ)
-
Outer Diameter D(φ)
-
Width B (or T)(mm)
-
RoHS Certificate
- Available
-
REACH Certificate
- Available
-
Customs tariff — weight
-
Customs tariff — weight unit
- kg
-
Type
- 5230
- 5231
-
Filter by CAD data type
- 3D
Filter by standard shipping days
-
- All
- 3 Days or Less
- 5 Days or Less
- 17 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
