Four point contact bearing / QJ3xx-N2 / similar to DIN 628-4 / FAG
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Inner Diameter d (φ) | Outer Diameter D (φ) | Width B (or T) (mm) | Basic Dynamic Load Rating (N) | Maximum Allowable Rotational Speed (1/min) | Load Direction | Basic Load Rating Static Rating (N) | Bearing clearance identifier | RoHS Certificate | REACH Certificate | Customs tariff — weight | Customs tariff — weight unit | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
324.65 € | 1 | Available | 5 Days | 75 | 160 | 37 | 229000 | 8300 | Radial | 204000 | - | - | - | - | - | ||
| - | 324.65 € | 1 | Available | 5 Days | 75 | 160 | 37 | - | - | - | - | - | - | - | - | - | |
287.95 € | 1 | Available | 3 Days | 80 | 170 | 39 | 226000 | 7000 | Radial | 220000 | - | - | - | - | - | ||
| - | 299.95 € | 1 | Available | 4 Days | 80 | 170 | 39 | - | 5500 | - | - | C3 | Available | Available | 4.65 | kg | |
401.54 € | 1 | Available | 3 Days | 85 | 180 | 41 | 248000 | 6600 | Radial | 255000 | - | - | - | - | - | ||
| - | 401.54 € | 1 | Available | 3 Days | 85 | 180 | 41 | - | - | - | - | - | - | - | - | - | |
449.15 € | 1 | Available | 3 Days | 90 | 190 | 43 | 265000 | 6300 | Radial | 285000 | - | - | - | - | - | ||
| - | 449.15 € | 1 | Available | 3 Days | 90 | 190 | 43 | - | - | - | - | - | - | - | - | - | |
597.18 € | 1 | Available | 3 Days | 95 | 200 | 45 | - | - | - | - | - | - | - | - | - | ||
| - | 597.18 € | 1 | Available | 3 Days | 95 | 200 | 45 | - | - | - | - | - | - | - | - | - | |
655.88 € | 1 | Available | 3 Days | 100 | 215 | 47 | 325000 | 5400 | Radial | 365000 | - | - | - | - | - | ||
| - | 655.88 € | 1 | Available | 3 Days | 100 | 215 | 47 | - | - | - | - | - | - | - | - | - | |
1,074.47 € | 1 | 17 Days | 110 | 240 | 50 | 345000 | 4950 | Radial | 415000 | - | - | - | - | - | |||
| - | 1,014.10 € | 1 | Available | 5 Days | 110 | 240 | 50 | - | - | - | - | - | - | - | - | - | |
1,006.37 € | 1 | Available | 3 Days | 120 | 260 | 55 | 385000 | 4550 | Radial | 485000 | - | - | - | - | - | ||
| - | 1,006.37 € | 1 | Available | 3 Days | 120 | 260 | 55 | - | - | - | - | - | - | - | - | - | |
1,457.93 € | 1 | 17 Days | 130 | 280 | 58 | 425000 | 4200 | Radial | 570000 | - | - | - | - | - | |||
| - | 1,376.01 € | 1 | Available | 5 Days | 130 | 280 | 58 | - | - | - | - | - | - | - | - | - | |
1,869.52 € | 1 | Available | 5 Days | 140 | 300 | 62 | 470000 | 3900 | Radial | 660000 | - | - | - | - | - | ||
| - | 1,980.80 € | 1 | 17 Days | 140 | 300 | 62 | - | - | - | - | - | - | - | - | - | ||
1,740.51 € | 1 | Available | 3 Days | 150 | 320 | 65 | 510000 | 3650 | Radial | 730000 | - | - | - | - | - | ||
| - | 1,740.51 € | 1 | Available | 3 Days | 150 | 320 | 65 | - | - | - | - | - | - | - | - | - | |
| - | 2,225.08 € | 1 | Available | 4 Days | 160 | 340 | 68 | - | 4950 | - | - | C3 | Available | Available | 32.8 | kg | |
2,996.98 € | 1 | Available | 3 Days | 170 | 360 | 72 | 590000 | 3200 | Radial | 920000 | - | - | - | - | - | ||
| - | 3,409.07 € | 1 | Available | 5 Days | 170 | 360 | 72 | - | - | - | - | - | - | - | - | - | |
4,022.06 € | 1 | Available | 3 Days | 180 | 380 | 75 | 690000 | 3000 | Radial | 1130000 | - | - | - | - | - | ||
| - | 4,022.06 € | 1 | Available | 3 Days | 180 | 380 | 75 | - | - | - | - | - | - | - | - | - |
Loading...
Configure
Basic Attributes
-
Inner Diameter d(φ)
-
Outer Diameter D(φ)
-
Width B (or T)(mm)
-
Basic Dynamic Load Rating(N)
-
Load Direction
- Radial
-
Bearing clearance identifier
- C3
-
RoHS Certificate
- Available
-
REACH Certificate
- Available
-
Customs tariff — weight
-
Customs tariff — weight unit
- kg
-
Type
- QJ
-
Filter by CAD data type
- 3D
Filter by standard shipping days
-
- All
- 3 Days or Less
- 4 Days or Less
- 5 Days or Less
- 17 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
