Housing units RCJT, two-bolt flanged housing units, cast iron, eccentric locking collar, R seals
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| RCJT17-XL |
| RCJT20-XL-N |
| RCJT25-XL-N |
| RCJT30-XL-N |
| RCJT35-XL-N |
| RCJT40-XL-N |
| RCJT45-XL |
| RCJT50-XL-N |
| RCJT55-XL |
| RCJT60-XL-N |
| RCJT65-214-XL |
| RCJT70-XL |
| RCJT75-XL |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Shaft Bore Dia. d (mm) | Basic Load Rating, Dynamic Rating (N) | Basic Load Rating, Static Rating (N) | Inner Diameter (mm) | Width (mm) | H (mm) | L (mm) | Housing | Customs tariff weight (kg) | Customs tariff weight unit | RoHS Certificate | REACH Certificate | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
29.34 € | 1 | Available | 3 Days | 17 | 10100 | 4750 | - | 40.5 | 99 | 57 | CJT03 | - | - | - | - | ||
29.72 € | 1 | Available | 3 Days | 20 | 13600 | 6600 | - | 45.6 | - | - | CJT04 | - | - | - | - | ||
32.85 € | 1 | Available | 3 Days | 25 | 14900 | 7800 | - | 46 | - | - | CJT05 | - | - | - | - | ||
53.80 € | 1 | Available | 5 Days | 30 | 20700 | 11300 | - | 50.2 | - | - | CJT06 | - | - | - | - | ||
46.18 € | 1 | Available | 3 Days | 35 | 25500 | 15300 | - | 53.5 | - | - | CJT07 | - | - | - | - | ||
53.03 € | 1 | Available | 3 Days | 40 | 34500 | 19800 | - | 59.1 | 172 | 105 | CJT08 | - | - | - | - | ||
63.78 € | 1 | Available | 3 Days | 45 | 34500 | 20400 | - | 59.1 | 180 | 111 | CJT09 | - | - | - | - | ||
95.65 € | 1 | Available | 5 Days | 50 | 37500 | 23200 | - | 66.2 | 190 | 116 | CJT10 | - | - | - | - | ||
127.50 € | 1 | Available | 5 Days | 55 | 46000 | 29000 | - | 74.6 | 222 | 134 | CJT11 | - | - | - | - | ||
161.57 € | 1 | Available | 5 Days | 60 | 56000 | 36000 | - | 80.9 | 238 | 138 | CJT12 | - | - | - | - | ||
- | 1 | 4 Days | 65 | 62000 | 44000 | 258 | 65 | - | - | CJT13/14 | 6.27 | kg | Available | Available | |||
198.46 € | 1 | Available | 3 Days | 70 | 66000 | 44000 | 258 | 70 | - | - | CJT13/14 | 6.02 | kg | Available | Available | ||
- | 1 | 4 Days | 75 | 66000 | 44500 | 258 | 75 | - | - | CJT15 | 5.88 | kg | Available | Available |
Loading...
Configure
Basic Attributes
-
Shaft Bore Dia. d(mm)
-
Inner Diameter(mm)
-
Width(mm)
-
H(mm)
-
L(mm)
-
Housing
-
Customs tariff weight(kg)
-
Customs tariff weight unit
- kg
-
RoHS Certificate
- Available
-
REACH Certificate
- Available
-
Type
- RCJT
-
Filter by CAD data type
- 3D
Filter by standard shipping days
-
- All
- 3 Days or Less
- 4 Days or Less
- 5 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
