L-section ring
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Inner Diameter (mm) | Outer Diameter (mm) | Width (mm) | |
|---|---|---|---|---|---|---|---|
308.68 € | 1 | Available | 5 Days | 160 | 188 | 19 | |
370.06 € | 1 | 17 Days | 170 | 201.8 | 21 | ||
382.31 € | 1 | 17 Days | 180 | 215 | 22.5 | ||
425.78 € | 1 | Available | 5 Days | 190 | 225 | 22.5 | |
741.12 € | 1 | 17 Days | 200 | 239.4 | 25.5 | ||
938.15 € | 1 | 17 Days | 220.07 | 261.7 | 27 | ||
1,022.87 € | 1 | 17 Days | 240.07 | 281.6 | 27 | ||
1,266.84 € | 1 | 17 Days | 260.08 | 309.3 | 31.5 | ||
2,003.88 € | 1 | 17 Days | 300.08 | 355.4 | 36 | ||
2,255.01 € | 1 | 17 Days | 320.08 | 375.4 | 36 | ||
- | 1 | 4 Days | 60 | 77.7 | 10 | ||
127.23 € | 1 | Available | 5 Days | 75 | 94.5 | 11 | |
131.18 € | 1 | 17 Days | 80 | 101.6 | 12.5 | ||
143.43 € | 1 | 17 Days | 85 | 107.6 | 12.5 | ||
143.43 € | 1 | Available | 5 Days | 90 | 114.4 | 14 | |
180.68 € | 1 | 17 Days | 95 | 120.6 | 14 | ||
182.21 € | 1 | 17 Days | 100 | 127.5 | 15 | ||
203.09 € | 1 | Available | 3 Days | 90 | 114.4 | 15 | |
269.15 € | 1 | Available | 5 Days | 100 | 127.5 | 16 | |
303.61 € | 1 | Available | 5 Days | 120 | 153.5 | 20 | |
320.22 € | 1 | Available | 3 Days | 130 | 164.2 | 21 | |
469.07 € | 1 | 17 Days | 140 | 180 | 23 | ||
211.31 € | 1 | 17 Days | 110 | 141.8 | 17 | ||
449.17 € | 1 | Available | 3 Days | 150 | 193.7 | 24.5 | |
542.05 € | 1 | 17 Days | 160 | 205.5 | 24.5 | ||
249.60 € | 1 | 17 Days | 120 | 153.5 | 17 | ||
342.50 € | 1 | 17 Days | 130 | 164.2 | 17 | ||
112.30 € | 1 | 17 Days | 55 | 77.6 | 15.5 | ||
157.20 € | 1 | 17 Days | 60 | 84.5 | 16 | ||
246.52 € | 1 | 17 Days | 75 | 104.3 | 19.5 | ||
251.65 € | 1 | 17 Days | 80 | 110.6 | 20 | ||
257.76 € | 1 | 17 Days | 85 | 117.9 | 22 | ||
265.41 € | 1 | 17 Days | 95 | 132.2 | 24.5 | ||
273.70 € | 1 | Available | 5 Days | 100 | 139.6 | 23.5 | |
381.29 € | 1 | 17 Days | 110 | 155.9 | 26.5 | ||
446.57 € | 1 | Available | 5 Days | 130.06 | 181.7 | 28 | |
692.38 € | 1 | Available | 5 Days | 140 | 196 | 31 | |
86.57 € | 1 | 17 Days | 50 | 71.4 | 13 | ||
79.57 € | 1 | Available | 3 Days | 55 | 77.6 | 14 | |
99.95 € | 1 | 17 Days | 60 | 84.5 | 14.5 | ||
94.75 € | 1 | Available | 3 Days | 65.05 | 90.5 | 15.5 | |
140.88 € | 1 | 17 Days | 75.05 | 104.1 | 16.5 | ||
193.12 € | 1 | Available | 5 Days | 80 | 110.6 | 17 | |
197.03 € | 1 | 17 Days | 85 | 117.9 | 18.5 | ||
171.06 € | 1 | Available | 7 Days | 90 | 124.2 | 18.5 | |
208.25 € | 1 | 17 Days | 95 | 132.2 | 20.5 | ||
263.39 € | 1 | 17 Days | 100 | 139.6 | 20.5 | ||
375.08 € | 1 | Available | 5 Days | 110 | 155.9 | 22 | |
399.91 € | 1 | Available | 5 Days | 120 | 168.6 | 22.5 | |
419.19 € | 1 | Available | 5 Days | 130.06 | 181.7 | 23 | |
99.74 € | 1 | 17 Days | 45 | 71.8 | 13.5 | ||
117.55 € | 1 | Available | 3 Days | 50 | 78.8 | 14.5 | |
167.42 € | 1 | 17 Days | 65.05 | 98.5 | 18 | ||
182.48 € | 1 | Available | 5 Days | 70 | 110.5 | 20 | |
237.21 € | 1 | Available | 5 Days | 80 | 122 | 22 | |
263.17 € | 1 | Available | 3 Days | 85 | 126 | 24 |
Loading...
Configure
Basic Attributes
-
Inner Diameter(mm)
-
Outer Diameter(mm)
-
Width(mm)
-
Type
- HJ1
- HJ2
- HJ3
- HJ4
Filter by standard shipping days
-
- All
- 3 Days or Less
- 4 Days or Less
- 5 Days or Less
- 7 Days or Less
- 17 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
