Needle roller bearings NA69, dimension series 49, to DIN 617 / ISO 1206
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| NA69/22-XL |
| NA69/28-XL |
| NA6901-XL |
| NA6902-XL |
| NA6903-XL |
| NA6904-XL |
| NA6905-XL |
| NA6906-XL |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Internal Diameter (mm) | Outer Diameter (mm) | Width (mm) | Allowable Rotational Speed (1/min) | Basic Load Rating, Dynamic Rating (N) | Basic Load Rating, Static Rating (N) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
39.86 € | 1 | Available | 3 Days | 22 | 39 | 30 | 15300 | 42000 | 55000 | ||
47.91 € | 1 | Available | 3 Days | 28 | 45 | 30 | 13600 | 45500 | 63000 | ||
21.25 € | 1 | Available | 3 Days | 12 | 24 | 22 | 23200 | 18100 | 21600 | ||
23.12 € | 1 | Available | 3 Days | 15 | 28 | 23 | 21100 | 19500 | 25500 | ||
24.85 € | 1 | Available | 3 Days | 17 | 30 | 23 | 20000 | 21100 | 29000 | ||
50.85 € | 1 | Available | 5 Days | 20 | 37 | 30 | 16900 | 40500 | 51000 | ||
55.75 € | 1 | Available | 5 Days | 25 | 42 | 30 | 14400 | 44000 | 59000 | ||
49.97 € | 1 | Available | 3 Days | 30 | 47 | 30 | 12600 | 49000 | 71000 |
Loading...
Configure
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
