Needle roller bearings RNA49, dimension series 49, to DIN 617 / ISO 1206
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Internal Diameter (mm) | Outer Diameter (mm) | Width (mm) | Allowable Rotational Speed (1/min) | Basic Load Rating, Dynamic Rating (N) | Basic Load Rating, Static Rating (N) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
18.32 € | 1 | Available | 3 Days | 28 | 39 | 17 | 15300 | 26000 | 29500 | ||
28.00 € | 1 | Available | 5 Days | 32 | 45 | 17 | 13600 | 27500 | 33500 | ||
23.34 € | 1 | Available | 3 Days | 40 | 52 | 20 | 11100 | 34500 | 47500 | ||
12.54 € | 1 | Available | 3 Days | 14 | 22 | 13 | 24600 | 9600 | 9200 | ||
13.31 € | 1 | Available | 3 Days | 16 | 24 | 13 | 23200 | 10600 | 10900 | ||
| - | 13.92 € | 1 | Available | 3 Days | 20 | 28 | 13 | - | - | - | |
20.58 € | 1 | Available | 5 Days | 22 | 30 | 13 | 20000 | 12400 | 14600 | ||
22.17 € | 1 | Available | 5 Days | 25 | 37 | 17 | 16900 | 23700 | 25500 | ||
25.00 € | 1 | Available | 5 Days | 30 | 42 | 17 | 14400 | 26500 | 31500 | ||
21.43 € | 1 | Available | 3 Days | 35 | 47 | 17 | 12600 | 28500 | 35500 | ||
24.85 € | 1 | Available | 3 Days | 42 | 55 | 20 | 10700 | 35500 | 50000 | ||
| - | 27.32 € | 1 | Available | 3 Days | 48 | 62 | 22 | - | - | - | |
41.38 € | 1 | Available | 5 Days | 52 | 68 | 22 | 8600 | 51000 | 73000 | ||
33.22 € | 1 | Available | 3 Days | 58 | 72 | 22 | 7800 | 53000 | 80000 | ||
40.25 € | 1 | Available | 3 Days | 63 | 80 | 25 | 7200 | 65000 | 100000 | ||
49.97 € | 1 | Available | 3 Days | 68 | 85 | 25 | 6700 | 68000 | 108000 | ||
85.28 € | 1 | Available | 5 Days | 72 | 90 | 25 | 6300 | 69000 | 112000 | ||
102.90 € | 1 | Available | 5 Days | 80 | 100 | 30 | 5700 | 95000 | 156000 | ||
114.05 € | 1 | Available | 5 Days | 85 | 105 | 30 | 5400 | 97000 | 162000 | ||
91.98 € | 1 | Available | 3 Days | 90 | 110 | 30 | 5100 | 101000 | 174000 | ||
116.51 € | 1 | Available | 3 Days | 100 | 120 | 35 | 4600 | 125000 | 237000 | ||
131.48 € | 1 | Available | 3 Days | 105 | 125 | 35 | 4400 | 129000 | 250000 | ||
200.85 € | 1 | Available | 5 Days | 110 | 130 | 35 | 4200 | 131000 | 260000 | ||
178.72 € | 1 | Available | 6 Days | 115 | 140 | 40 | 4000 | 144000 | 270000 | ||
266.75 € | 1 | Available | 5 Days | 125 | 150 | 40 | 3700 | 149000 | 290000 | ||
225.98 € | 1 | Available | 3 Days | 135 | 165 | 45 | 3400 | 205000 | 390000 | ||
264.34 € | 1 | Available | 3 Days | 150 | 180 | 50 | 3100 | 229000 | 470000 | ||
304.58 € | 1 | Available | 3 Days | 160 | 190 | 50 | 2900 | 237000 | 500000 |
Loading...
Configure
Basic Attributes
-
Internal Diameter(mm)
-
Outer Diameter(mm)
-
Width(mm)
-
Type
- RNA
-
Filter by CAD data type
- 3D
Filter by standard shipping days
-
- All
- 3 Days or Less
- 5 Days or Less
- 6 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
