Self-aligning ball bearings / double row / 22xx / internal clearance selectable / cage selectable / similar to DIN 630 / 22 / similar to DIN 630 / FAG

Configure

Inner Diameter d(φ)
- 10
- 12
- 15
- 17
- 20
- 25
- 30
- 35
- 40
- 45
- 50
- 55
- 60
- 65
- 70
- 75
- 80
- 85
- 90
- 95
- 100
- 110
Outer Diameter D(φ)
- 30
- 32
- 35
- 40
- 47
- 52
- 62
- 72
- 80
- 85
- 90
- 100
- 110
- 120
- 125
- 130
- 140
- 150
- 160
- 170
- 180
- 200
Width B (or T)(mm)
- 14
- 16
- 18
- 20
- 23
- 25
- 28
- 31
- 33
- 36
- 40
- 43
- 46
- 53
Basic Dynamic Load Rating(N)
- 8800
- 9400
- 9600
- 11800
- 14700
- 17300
- 26000
- 28500
- 32500
- 33000
- 39000
- 44000
- 44500
- 48000
- 49500
- 58000
- 59000
- 71000
- 84000
- 98000
- 126000
Load Direction
- Radial
Type
- 220
- 221
- 222
CAD
- 3D
Est. shipping days
- All
- Within 3 working days
- Within 5 working days
- Within 17 working days

Self-aligning ball bearings / double row / 22xx / internal clearance selectable / cage selectable / similar to DIN 630 / 22 / similar to DIN 630 / FAG

Catalog

Part number:

Still undefined. 41 possible part numbers found.

Part number list
Catalog

Part number list

Number of items

Part number

Inner Diameter d

(φ)

Outer Diameter D

(φ)

Width B (or T)

(mm)

Basic Dynamic Load Rating

(N)

Maximum Allowable Rotational Speed

(1/min)

Load Direction

Basic Load Rating Static Rating

(N)

Minimum order quantity

Data sheet	10	30	14	8800	25500	Radial	1740	1 pieces
-	10	30	14	-	-	-	-	1 pieces
Data sheet	12	32	14	9400	24200	Radial	1940	1 pieces
-	12	32	14	-	-	-	-	1 pieces
Data sheet	15	35	14	9600	22200	Radial	2100	1 pieces
-	15	35	14	-	-	-	-	1 pieces
Data sheet	17	40	16	11800	19100	Radial	2750	1 pieces
-	17	40	16	-	-	-	-	1 pieces
Data sheet	20	47	18	14700	16300	Radial	3550	1 pieces
-	20	47	18	-	-	-	-	1 pieces
Data sheet	25	52	18	17300	14400	Radial	4450	1 pieces
-	25	52	18	-	-	-	-	1 pieces
Data sheet	30	62	20	26000	11500	Radial	6900	1 pieces
-	30	62	20	-	-	-	-	1 pieces
Data sheet	35	72	23	33000	9800	Radial	9000	1 pieces
-	35	72	23	-	-	-	-	1 pieces
Data sheet	40	80	23	32500	8900	Radial	9500	1 pieces
-	40	80	23	-	-	-	-	1 pieces
Data sheet	45	85	23	28500	8600	Radial	9000	1 pieces
-	45	85	23	-	-	-	-	1 pieces
Data sheet	50	90	23	28500	8100	Radial	9500	1 pieces
-	50	90	23	-	-	-	-	1 pieces
Data sheet	55	100	25	39000	7000	Radial	12500	1 pieces
-	55	100	25	-	-	-	-	1 pieces
Data sheet	60	110	28	48000	6300	Radial	16500	1 pieces
-	60	110	28	-	-	-	-	1 pieces
Data sheet	65	120	31	58000	5600	Radial	19200	1 pieces
-	65	120	31	-	-	-	-	1 pieces
Data sheet	70	125	31	44000	8800	Radial	17100	1 pieces
Data sheet	75	130	31	44500	5600	Radial	17800	1 pieces
-	75	130	31	-	-	-	-	1 pieces
Data sheet	80	140	33	49500	5300	Radial	19900	1 pieces
-	80	140	33	-	-	-	-	1 pieces
Data sheet	85	150	36	59000	7200	Radial	23600	1 pieces
Data sheet	90	160	40	71000	4400	Radial	28500	1 pieces
-	90	160	40	-	-	-	-	1 pieces
Data sheet	95	170	43	84000	6100	Radial	34500	1 pieces
Data sheet	100	180	46	98000	5700	Radial	40500	1 pieces
-	100	180	46	-	-	-	-	1 pieces
Data sheet	110	200	53	126000	5000	Radial	52000	1 pieces
-	110	200	53	-	-	-	-	1 pieces

Unit price (excluding VAT)(Unit price including VAT)	Standard shipping days

18.81 € ( 22.38 € )	5 working days
18.81 € ( 22.38 € )	5 working days
22.40 € ( 26.66 € )	5 working days
20.40 € ( 24.28 € )	3 working days
22.63 € ( 26.93 € )	5 working days
22.63 € ( 26.93 € )	5 working days
23.08 € ( 27.47 € )	5 working days
23.08 € ( 27.47 € )	5 working days
23.32 € ( 27.75 € )	5 working days
21.25 € ( 25.29 € )	3 working days
25.15 € ( 29.93 € )	5 working days
22.91 € ( 27.26 € )	3 working days
27.18 € ( 32.34 € )	5 working days
27.18 € ( 32.34 € )	5 working days
32.36 € ( 38.51 € )	5 working days
32.36 € ( 38.51 € )	5 working days
36.54 € ( 43.48 € )	5 working days
36.54 € ( 43.48 € )	5 working days
42.82 € ( 50.96 € )	5 working days
42.82 € ( 50.96 € )	5 working days
47.85 € ( 56.94 € )	5 working days
47.85 € ( 56.94 € )	5 working days
58.55 € ( 69.67 € )	5 working days
58.55 € ( 69.67 € )	5 working days
71.32 € ( 84.87 € )	5 working days
71.32 € ( 84.87 € )	5 working days
79.77 € ( 94.93 € )	3 working days
87.58 € ( 104.22 € )	5 working days
242.80 € ( 288.93 € )	3 working days
132.08 € ( 157.18 € )	5 working days
132.08 € ( 157.18 € )	5 working days
160.15 € ( 190.58 € )	5 working days
160.15 € ( 190.58 € )	5 working days
280.25 € ( 333.50 € )	3 working days
215.49 € ( 256.43 € )	3 working days
236.60 € ( 281.55 € )	5 working days
388.51 € ( 462.33 € )	5 working days
485.98 € ( 578.32 € )	17 working days
458.66 € ( 545.81 € )	5 working days
631.57 € ( 751.57 € )	17 working days
596.09 € ( 709.35 € )	5 working days

Catalog
