MB1W Series Square-Tube Type Air Cylinder, Standard Type, Double Acting, Double Rod

MB1W Series Square-Tube Type Air Cylinder, Standard Type, Double Acting, Double Rod

Caution

  • ■ SMC Product Line
    Webpages for products currently without individual pages on this site will be released on an ad-hoc basis.
  • Product images may be representative images only. Please refer to the manufacturer's catalog for shape details.
  • CAD data is not available for some model numbers.

Part number:

Still undefined. 11 possible part numbers found.
Quantity:

Part number list

Number of items
  • 1
    • Part number
    MDB1WB32TF-100Z
    MDB1WB32TF-125Z
    MDB1WB40-400Z
    MDB1WB63-50Z
    MDB1WB63-80Z
    MDB1WB63-125Z
    MDB1WB63TF-80Z
    MDB1WB63TF-125Z
    MDB1WB80-300Z
    MDB1WF50-50Z
    MDB1WF50-250Z

    Cylinder (Tube) Inner Diameter

    (Ø)

    Stroke

    (mm)

    Port thread type

    Auto Switch

    Type of Mount Support

    Connector type

    		Minimum order quantity
    32
    100
    G
    None
    Basic type
    -
    1 pieces
    32
    125
    G
    None
    Basic type
    -
    1 pieces
    40
    400
    Rc
    None
    Basic type
    -
    1 pieces
    63
    50
    Rc
    None
    Basic type
    -
    1 pieces
    63
    80
    Rc
    None
    Basic type
    -
    1 pieces
    63
    125
    Rc
    None
    Basic type
    -
    1 pieces
    63
    80
    G
    Without switch
    Basic type
    None
    1 pieces
    63
    125
    G
    Without switch
    Basic type
    None
    1 pieces
    80
    300
    Rc
    None
    Basic type
    -
    1 pieces
    50
    50
    Rc
    None
    Flange type
    -
    1 pieces
    50
    250
    Rc
    Without switch
    Flange type
    None
    1 pieces
    Unit price (excluding VAT)(Unit price including VAT)
    Standard shipping days
    202.48 €
    ( 240.95 € )
    26 working days
    206.98 €
    ( 246.31 € )
    26 working days
    292.21 €
    ( 347.73 € )
    26 working days
    291.15 €
    ( 346.47 € )
    26 working days
    311.31 €
    ( 370.46 € )
    26 working days
    324.48 €
    ( 386.13 € )
    26 working days
    311.31 €
    ( 370.46 € )
    26 working days
    321.40 €
    ( 382.47 € )
    26 working days
    434.77 €
    ( 517.38 € )
    26 working days
    252.39 €
    ( 300.34 € )
    26 working days
    333.19 €
    ( 396.50 € )
    26 working days
  • 1

    • More Information

    Basic information

    A lightweight air cylinder made lighter by changing the shape of the rod cover and head cover.
    [Features]
    · Square tube type.
    · Can mount small auto switches on 4 surfaces.
    · Without auto switch (MB1W) or with auto switch (built-in magnet) (MDB1W).
    · Mounting: basic type, foot type, flange type.
    · Port thread types: Rc, NPT, G.
    · Rod boot material (J): nylon tarpaulin, maximum ambient temperature 70°C.
    · Rod boot material (K): heat-resistant tarpaulin, maximum ambient temperature 110°C*.
    *Maximum ambient temperature for the rod boot unit.

    Caution

    • ■ SMC Product Line
      Webpages for products currently without individual pages on this site will be released on an ad-hoc basis.
    • Product images may be representative images only. Please refer to the manufacturer's catalog for shape details.
    • CAD data is not available for some model numbers.
