AS*000E, Speed Controller, Residual Pressure Exhaust
· A speed controller integrated with a residual pressure release valve.
· Releases residual pressure with the push of a button.
· The pressure-release button is in clearly visible red.
(i)Remark
- For specifications and details, please refer to the catalog.
- Product images may be representative images. Refer to the catalog for details.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| AS2000E-01 |
| AS2000E-02 |
| AS2000E-F01 |
| AS2000E-F02 |
| AS2000E-N01 |
| AS3000E-02 |
| AS3000E-03 |
| AS3000E-F03 |
| AS4000E-02 |
| AS4000E-03 |
| AS4000E-04 |
| AS4000E-F04 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Main Body Material | Thread Material | Operating Temperature Range (℃) | Operating Pressure Range (MPa) | Max. Flow (l/min) | Connection Dia. | Types of Screw | Body Size | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
20.44 € | 1 | 4 Days | Zinc Alloy | Zinc Alloy | - | - | - | 1/8 | Rc | 1/8, 1/4 Standard | ||
20.44 € | 1 | 4 Days | Zinc Alloy | Zinc Alloy | - | - | - | 1/4 | Rc | 1/8, 1/4 Standard | ||
20.44 € | 1 | 10 Days | Zinc Alloy | Zinc Alloy | -5～60 | 0.05 to 1.0～ | 340 | 1/8 | G | 1/8, 1/4 standards | ||
20.44 € | 1 | 26 Days | Zinc Alloy | Zinc Alloy | -5～60 | 0.05 to 1.0～ | 340 | 1/4 | G | 1/8, 1/4 standards | ||
20.44 € | 1 | 26 Days | Zinc Alloy | Zinc Alloy | -5～60 | 0.05 to 1.0～ | 340 | 1/8 | NPT | 1/8, 1/4 standards | ||
23.02 € | 1 | 26 Days | [Aluminum Alloy] Alloy Aluminum | [Aluminum Alloy] Aluminum Alloy | -5～60 | 0.05 to 1.0～ | 810 | 1/4 | Rc | 3/8 standard | ||
23.02 € | 1 | 4 Days | [Aluminum Alloy] Alloy Aluminum | [Aluminum Alloy] Aluminum Alloy | - | - | - | 3/8 | Rc | 3/8 Standard | ||
23.02 € | 1 | 26 Days | [Aluminum Alloy] Alloy Aluminum | [Aluminum Alloy] Aluminum Alloy | -5～60 | 0.05 to 1.0～ | 810 | 3/8 | G | 3/8 standard | ||
43.47 € | 1 | 26 Days | [Aluminum Alloy] Alloy Aluminum | [Aluminum Alloy] Aluminum Alloy | -5～60 | 0.05 to 1.0～ | 1670 | 1/4 | Rc | 1/2 standard | ||
43.47 € | 1 | 4 Days | [Aluminum Alloy] Alloy Aluminum | [Aluminum Alloy] Aluminum Alloy | -5～60 | 0.05 to 1.0～ | 1670 | 3/8 | Rc | 1/2 standard | ||
43.47 € | 1 | 4 Days | [Aluminum Alloy] Alloy Aluminum | [Aluminum Alloy] Aluminum Alloy | -5～60 | 0.05 to 1.0～ | 1670 | 1/2 | Rc | 1/2 standard | ||
43.47 € | 1 | 26 Days | [Aluminum Alloy] Alloy Aluminum | [Aluminum Alloy] Aluminum Alloy | -5～60 | 0.05 to 1.0～ | 1670 | 1/2 | G | 1/2 standard |
Loading...
Basic information
| Type | Speed Controller | Main Body Shape | Cylinder direct-connected elbow type | Control Direction | Meter-Out |
|---|---|---|---|---|---|
| Joint Type | Both sides tapped | Usage Environment/Application | Standard | Knob Type | Push Lock Type |
| Lock Nut Type | Hexagon Shape Lock Nut |
Configure
Basic Attributes
-
Main Body Material
- Aluminum Alloy
- Zinc Alloy
- Aluminum Alloy
-
Thread Material
- Aluminum Alloy
- Zinc Alloy
- Aluminum Alloy
-
Connection Dia.
- 1/2
- 1/4
- 1/8
- 3/8
-
Types of Screw
-
Body Size
-
Type
- AS2000E
- AS3000E
- AS4000E
-
Filter by CAD data type
- 2D
- 3D
Filter by standard shipping days
-
- All
- 4 Days or Less
- 10 Days or Less
- 26 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
