Configure

Thread Nominal M
Outer Diameter Dm(mm)
- 18
- 22
- 25
- 28
- 32
- 38
- 45
- 52
- 58
- 65
- 70
- 75
- 80
- 85
- 92
- 98
- 105
- 110
- 120
- 125
- 130
- 140
- 145
- 155
- 165
- 180
- 195
- 210
- 220
- 230
- 240
- 250
Thickness B(mm)
- 4
- 5
- 6
- 7
- 8
- 9
- 10
- 11
- 12
- 13
- 15
- 16
- 17
- 18
- 19
- 20
- 21
- 22
- 24
- 25
- 26
- 27
- 28
- 29
D(mm)
- 13.5
- 17
- 21
- 24
- 26
- 32
- 38
- 44
- 50
- 56
- 61
- 67
- 73
- 79
- 85
- 90
- 95
- 102
- 108
- 113
- 120
- 126
- 133
- 138
- 149
- 160
- 171
- 182
- 193
- 203
- 214
- 226
m(mm)
- 3
- 4
- 5
- 6
- 7
- 8
- 10
- 12
- 14
- 16
- 18
n(mm)
- 2
- 2.5
- 3
- 3.5
- 4
- 5
- 6
- 7
- 8
Mass(kg)
- 0.004
- 0.007
- 0.01
- 0.013
- 0.015
- 0.02
- 0.043
- 0.058
- 0.08
- 0.109
- 0.13
- 0.145
- 0.16
- 0.19
- 0.22
- 0.27
- 0.365
- 0.41
- 0.525
- 0.59
- 0.665
- 0.795
- 0.885
- 0.985
- 1.125
- 1.425
- 1.88
- 2.315
- 2.595
- 2.83
- 3.08
- 3.385
CAD
- 2D
- 3D
Est. shipping days
- All
- Within 21 working days

Slot nut / KM

Slot nut / KM

Catalog

Part number:

Still undefined. 32 possible part numbers found.

Part number list
More Information
Catalog

Part number list

Number of items

Part number

Thread Nominal M

Outer Diameter Dm

(mm)

Thickness B

(mm)

D

(mm)

m

(mm)

n

(mm)

Mass

(kg)

Minimum order quantity

0.391"x32F	18	4	13.5	3	2	0.004	1 pieces
1.967"x18F	70	11	61	6	2.5	0.13	1 pieces
2.157"x18F	75	11	67	7	3	0.145	1 pieces
2.360"x18F	80	11	73	7	3	0.16	1 pieces
2.548"x18F	85	12	79	7	3	0.19	1 pieces
0.469"x32F	22	4	17	3	2	0.007	1 pieces
2.751"x18F	92	12	85	8	3.5	0.22	1 pieces
2.933"x12F	98	13	90	8	3.5	0.27	1 pieces
3.137"x12F	105	15	95	8	3.5	0.365	1 pieces
3.340"x12F	110	16	102	8	3.5	0.41	1 pieces
3.527"x12F	120	16	108	10	4	0.525	1 pieces
3.730"x12F	125	17	113	10	4	0.59	1 pieces
3.918"x12F	130	18	120	10	4	0.665	1 pieces
4.122"x12F	140	18	126	12	5	0.795	1 pieces
4.325"x12F	145	19	133	12	5	0.885	1 pieces
0.586"x32F	25	5	21	4	2	0.01	1 pieces
4.716"x12F	155	20	138	12	5	0.985	1 pieces
5.106"x12F	165	21	149	12	5	1.125	1 pieces
5.497"x12F	180	22	160	14	6	1.425	1 pieces
5.888"x12F	195	24	171	14	6	1.88	1 pieces
6.284"x8F	210	25	182	16	7	2.315	1 pieces
0.664"x32F	28	5	24	4	2	0.013	1 pieces
6.659"x8F	220	26	193	16	7	2.595	1 pieces
7.066"x8F	230	27	203	18	8	2.83	1 pieces
7.472"x8F	240	28	214	18	8	3.08	1 pieces
7.847"x8F	250	29	226	18	8	3.385	1 pieces
0.781"x32F	32	6	26	4	2	0.02	1 pieces
0.969"x32F	38	7	32	5	2	0.015	1 pieces
1.173"x18F	45	7	38	5	2	0.043	1 pieces
1.376"x18F	52	8	44	5	2	0.058	1 pieces
1.563"x18F	58	9	50	6	2.5	0.08	1 pieces
1.767"x18F	65	10	56	6	2.5	0.109	1 pieces

Unit price (excluding VAT)(Unit price including VAT)	Standard shipping days

7.90 € ( 9.40 € )	21 working days
9.98 € ( 11.88 € )	21 working days
11.33 € ( 13.48 € )	21 working days
12.70 € ( 15.11 € )	21 working days
14.77 € ( 17.58 € )	21 working days
7.90 € ( 9.40 € )	21 working days
14.93 € ( 17.77 € )	21 working days
19.25 € ( 22.91 € )	21 working days
22.68 € ( 26.99 € )	21 working days
24.92 € ( 29.65 € )	21 working days
35.13 € ( 41.80 € )	21 working days
40.80 € ( 48.55 € )	21 working days
40.80 € ( 48.55 € )	21 working days
43.40 € ( 51.65 € )	21 working days
43.40 € ( 51.65 € )	21 working days
7.90 € ( 9.40 € )	21 working days
55.98 € ( 66.62 € )	21 working days
62.63 € ( 74.53 € )	21 working days
88.68 € ( 105.53 € )	21 working days
98.33 € ( 117.01 € )	21 working days
101.72 € ( 121.05 € )	21 working days
7.90 € ( 9.40 € )	21 working days
112.07 € ( 133.36 € )	21 working days
126.78 € ( 150.87 € )	21 working days
139.28 € ( 165.74 € )	21 working days
154.08 € ( 183.36 € )	21 working days
7.90 € ( 9.40 € )	21 working days
7.90 € ( 9.40 € )	21 working days
7.90 € ( 9.40 € )	21 working days
9.10 € ( 10.83 € )	21 working days
9.27 € ( 11.03 € )	21 working days
9.50 € ( 11.30 € )	21 working days

More Information

Basic information

Basic information

Locknuts can be used to locate bearings on shafts or adapter sleeves. They also give easier mounting of bearings with a tapered shaft seat

Catalog

Products homepage

Catalog (2-page spread)
