Swivel Castors with double stop in the flow and polypropylene wheel
[Specifications]
・Rolls and case type: Steering housing
・Housing material RR: Steel galvanized
・Rim material: Polypropylene
・Tread material: Polypropylene
・Tread color: White
・Wheel diameter(mm): 250
・Wheel width(mm): 60
・Load capacity dynamic(kg): 350
・Stop Type: DS-V (double stop in the lead)
・Weight(kg): 3.75
[Features]
・steel sheet housing, galvanized
・fork head with double ball bearing
・seal with integrated ball spacer
・(old designation:LCW)
・Rolls and case type: Steering housing
・Housing material RR: Steel galvanized
・Rim material: Polypropylene
・Tread material: Polypropylene
・Tread color: White
・Wheel diameter(mm): 250
・Wheel width(mm): 60
・Load capacity dynamic(kg): 350
・Stop Type: DS-V (double stop in the lead)
・Weight(kg): 3.75
[Features]
・steel sheet housing, galvanized
・fork head with double ball bearing
・seal with integrated ball spacer
・(old designation:LCW)
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
L-IK-PPH-250-K-3-DSV
- Product data
- CAD data not available
Basic information
| Plate length(mm) | 135 | Plate width(mm) | 110 | Wheel diameter(mm) | 250 |
|---|---|---|---|---|---|
| Wheel width(mm) | 60 | Load capacity dynamic(kg) | 350 | overall height(mm) | 290 |
| Discharge swivel castor(mm) | 66 | Rolls and case type | Steering housing | Mounting type | Mounting plate |
| Wheel bearing | Ball-bearing | Bolt Hole Length(mm) | 105 | Housing material RR | Steel galvanized |
| Bolt hole width(mm) | 80 | Material Description Housing | Lightweight, pressed sheet steel housing, galvanized | Surface coating | galvanized |
| Number of wheels [piece] | 1 | Rim material | Polypropylene | Tread material | Polypropylene |
| Swivel Radius(mm) | 191 | electrically conductive | none | Tread color | White |
| Tread type | cylindrical | Stop Type | DS-V (double stop in the lead) | Housing classification | Standard housing IL |
| Weight(kg) | 3.75 |
This page is Swivel Castors with double stop in the flow and polypropylene wheel, part number L-IK-PPH-250-K-3-DSV.
You can find the detail information about specifications and dimensions on part number L-IK-PPH-250-K-3-DSV.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
