Pneumatic Power Cylinder WK

Pneumatic Power Cylinder WK

DESTACO

DESTACO

Destaco’s WK Series pneumatic power cylinder is designed with an ISO fit and can provide over 13,000lbf (60kN) of rod force in a simple double acting pneumatics-only package. Operation is based on the wedge lever principle. These double acting cylinders feature two steps of stroke: the forward stroke to move a certain distance and the power stroke with an amplified force on a short (6-7mm) distance. The rod force in the range of the forward stroke is that of a traditional pneumatic cylinder; the rod force in the range of the power stroke features a mechanical advantage of up to 10:1. The pneumatic power cylinder is ideally suited as the power source for tools and devices for the following applications - clamping, punching, stamping, notching, coining, riveting, pressing, and clinching.

Data sheet

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.


Data to be displayed
30
45
60
  1. 1
  2. 2
  3. Next >>
Part Number
WK1000-15-7-1
WK1000-15-7-A
WK1000-15-7-K
WK1000-30-7-1
WK1000-30-7-A
WK1000-50-7-1
WK1000-50-7-A
WK1000-70-7-1
WK1000-70-7-A
WK1000-120-7-1
WK1000-120-7-A
WK1000-200-7-1
WK1000-200-7-A
WK3000-15-6-1
WK3000-15-6-A
WK3000-30-6-1
WK3000-30-6-A
WK3000-50-6-1
WK3000-50-6-A
WK3000-70-6-1
WK3000-70-6-A
WK3000-120-6-1
WK3000-120-6-A
WK3000-120-6-K
WK3000-150-6-1
WK3000-200-6-1
WK3000-200-6-A
WK400-15-6-1
WK400-15-6-A
WK400-15-6-K
WK400-30-6-1
WK400-30-6-A
WK400-50-6-1
WK400-50-6-A
WK400-70-6-1
WK400-70-6-A
WK400-120-6-1
WK400-120-6-A
WK400-200-6-1
WK400-200-6-A
WK4500-15-6-1
WK4500-15-6-A
WK4500-30-6-A
WK4500-50-6-1
WK4500-50-6-A
WK4500-70-6-1
WK4500-70-6-A
WK4500-200-6-1
WK4500-200-6-A
WK6000-30-6
WK6000-50-6
WK6000-70-6
WK6000-120-6
WK600-15-6-1
WK600-15-6-A
WK600-15-6-K
WK600-30-6-1
WK600-30-6-A
WK600-50-6-1
WK600-50-6-A
Part Number
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?
Stroke: L
(mm) 		Product Type Max. Clamping Force
(N) 		Cylinder Bore
(mm) 		Power Stroke
(mm) 		Stroke Frequency depending on total stroke
(per minute) 		End position control by magnetic field sensors

3,281.25 €

1 30 Days 15Piston rod with ISO fit100006375 to 30No

3,351.97 €

1 30 Days 15Piston rod with ISO fit100006375 to 30Yes

3,687.18 €

1 30 Days 15Piston rod with ISO fit-----

2,982.96 €

1 30 Days 30Piston rod with ISO fit100006375 to 30No

3,687.18 €

1 30 Days 30Piston rod with ISO fit100006375 to 30Yes

2,982.96 €

1 30 Days 50Piston rod with ISO fit100006375 to 30No

3,713.76 €

1 30 Days 50Piston rod with ISO fit100006375 to 30Yes

3,365.80 €

1 30 Days 70Piston rod with ISO fit100006375 to 30No

3,648.52 €

1 30 Days 70Piston rod with ISO fit100006375 to 30Yes

3,629.17 €

1 30 Days 120Piston rod with ISO fit100006375 to 30No

4,180.09 €

1 30 Days 120Piston rod with ISO fit100006375 to 30Yes

3,745.18 €

1 30 Days 200Piston rod with ISO fit100006375 to 30No

3,958.22 €

1 30 Days 200Piston rod with ISO fit100006375 to 30Yes

4,643.57 €

1 30 Days 15Piston rod with ISO fit300008565 to 25No

5,251.99 €

1 30 Days 15Piston rod with ISO fit300008565 to 25Yes

5,107.90 €

1 30 Days 30Piston rod with ISO fit300008565 to 25No

5,832.80 €

1 30 Days 30Piston rod with ISO fit300008565 to 25Yes

5,107.90 €

1 30 Days 50Piston rod with ISO fit300008565 to 25No

5,864.20 €

1 30 Days 50Piston rod with ISO fit300008565 to 25Yes

4,748.99 €

1 30 Days 70Piston rod with ISO fit300008565 to 25No

5,460.68 €

1 30 Days 70Piston rod with ISO fit300008565 to 25Yes

5,038.95 €

1 30 Days 120Piston rod with ISO fit300008565 to 25No

5,858.25 €

1 30 Days 120Piston rod with ISO fit300008565 to 25Yes

5,858.25 €

1 30 Days 120Piston rod with ISO fit-----

5,238.84 €

1 30 Days 150Piston rod with ISO fit-----

5,661.25 €

1 30 Days 200Piston rod with ISO fit300008565 to 25No

6,121.81 €

1 30 Days 200Piston rod with ISO fit300008565 to 25Yes

1,140.46 €

1 30 Days 15Piston rod with ISO fit40004065 to 30No

1,473.91 €

1 30 Days 15Piston rod with ISO fit40004065 to 30Yes

1,339.92 €

1 30 Days 15Piston rod with ISO fit-----

1,140.46 €

1 30 Days 30Piston rod with ISO fit40004065 to 30No

1,500.49 €

1 30 Days 30Piston rod with ISO fit40004065 to 30Yes

1,140.46 €

1 30 Days 50Piston rod with ISO fit40004065 to 30No

1,396.60 €

1 30 Days 50Piston rod with ISO fit40004065 to 30Yes

1,171.87 €

1 30 Days 70Piston rod with ISO fit40004065 to 30No

1,560.90 €

1 30 Days 70Piston rod with ISO fit40004065 to 30Yes

1,120.28 €

1 30 Days 120Piston rod with ISO fit40004065 to 30No

1,502.45 €

1 30 Days 120Piston rod with ISO fit40004065 to 30Yes

1,448.72 €

1 30 Days 200Piston rod with ISO fit40004065 to 30No

1,860.50 €

1 30 Days 200Piston rod with ISO fit40004065 to 30Yes

6,676.02 €

1 25 Days 15Piston rod with ISO fit4500010065 to 25No

6,649.01 €

1 25 Days 15Piston rod with ISO fit4500010065 to 25Yes

7,371.90 €

1 25 Days 30Piston rod with ISO fit4500010065 to 25Yes

6,676.02 €

1 25 Days 50Piston rod with ISO fit4500010065 to 25No

6,728.08 €

1 25 Days 50Piston rod with ISO fit4500010065 to 25Yes

6,847.56 €

1 25 Days 70Piston rod with ISO fit4500010065 to 25No

7,632.90 €

1 25 Days 70Piston rod with ISO fit4500010065 to 25Yes

6,622.68 €

1 25 Days 200Piston rod with ISO fit4500010065 to 25No

7,616.69 €

1 25 Days 200Piston rod with ISO fit4500010065 to 25Yes

8,707.19 €

1 45 Days 30Piston rod with ISO fit6000012565 to 25No

8,759.93 €

1 45 Days 50Piston rod with ISO fit6000012565 to 25No

8,863.16 €

1 45 Days 70Piston rod with ISO fit6000012565 to 25No

10,286.18 €

1 45 Days 70Piston rod with ISO fit6000012565 to 25No

1,891.93 €

1 30 Days 15Piston rod with ISO fit60005065 to 30No

2,065.89 €

1 30 Days 15Piston rod with ISO fit60005065 to 30Yes

1,878.08 €

1 30 Days 15Piston rod with ISO fit-----

1,735.29 €

1 30 Days 30Piston rod with ISO fit60005065 to 30No

1,900.03 €

1 30 Days 30Piston rod with ISO fit60005065 to 30Yes

1,757.28 €

1 30 Days 50Piston rod with ISO fit60005065 to 30No

1,919.82 €

1 30 Days 50Piston rod with ISO fit60005065 to 30Yes

Loading...

  1. 1
  2. 2
  3. Next >>

Basic information

Operating Temperature(℃) -5::75 Operating Pressure(MPa) 0.3::0.6

Configure

Clear all

70Suggestion of an applicable part number.

View Part Numbers

Some specification is not specified yet.
The part number is completed.

Basic Attributes

  • Stroke: L(mm)

    • 15
    • 30
    • 50
    • 70
    • 120
    • 150
    • 200

    Clear

  • Product Type

    • Piston rod with ISO fit
    • Piston with dual rods

    Clear

  • Max. Clamping Force(N)

    • 4000
    • 6000
    • 10000
    • 20000
    • 30000
    • 45000
    • 60000

    Clear

  • Cylinder Bore(mm)

    • 40
    • 50
    • 63
    • 70
    • 85
    • 100
    • 125

    Clear

  • Power Stroke(mm)

    • 6
    • 7

    Clear

  • Stroke Frequency depending on total stroke(per minute)

    • 5 to 25
    • 5 to 30

    Clear

  • End position control by magnetic field sensors

    • No
    • Yes

    Clear
